Vintage 1906 LED CLASSIC A

Choose your product version

OVERVIEW

Product description Base (standard designation) Nominal wattage Nominal voltage Nominal lamp life time Nominal luminous flux Claimed equiv. conventional lamp power Beam angle Dimmable
Vintage 1906 Classic A 22 Filament 2.5W 824 Gold E27 E27 2.5 W 220…240 V 15000 h 220 lm 22 W 300 ° No
Vintage 1906 Classic A 35 Filament 4W 824 Gold E27 E27 4 W 220…240 V 15000 h 410 lm 35 W 300 ° No
Vintage 1906 Classic A 50 Filament 6.5W 824 Gold E27 E27 6.5 W 220…240 V 15000 h 650 lm 50 W 300 ° No
Vintage 1906 Classic A 63 Filament 7.5W 824 Gold E27 E27 7.5 W 220…240 V 15000 h 865 lm 63 W 300 ° No
Vintage 1906 Edison 28 Filament Big Grape 4W 820 Gold E27 E27 4 W 220…240 V 15000 h 300 lm 28 W 300 ° No
Vintage 1906 Edison 15 Filament Big Grape 4W 818 Smoke E27 E27 4 W 220…240 V 15000 h 140 lm 15 W 330 ° No
Vintage 1906 Classic A 40 Spiral Filament 3.4W 827 Clear E27 E27 3.4 W 220…240 V 15000 h 470 lm 40 W 300 ° No
Vintage 1906 Classic A 40 Spiral Filament 4.9W 927 Gold E27 E27 4.9 W 220…240 V 15000 h 470 lm 40 W 300 ° No
Vintage 1906 Classic A 60 Spiral Filament 5.9W 827 Clear E27 E27 5.9 W 220…240 V 15000 h 806 lm 60 W 300 ° No


Vintage 1906 Classic A 22 Filament 2.5W 824 Gold E27

Product benefits
  • Lower energy consumption than incandescent or halogen lamps
  • Instant 100 % light, no warm-up time
  • Can be easily fitted instead of ordinary light bulbs
  • Lamps with innovative LED "filament" technology

PRODUCT DETAILS

Electrical data

Nominal wattage 2.5 W
Construction wattage 2.50 W
Nominal voltage 220…240 V
Operating mode AC Mains
Claimed equiv. conventional lamp power 22 W
Nominal current 19 mA
Type of current AC
Inrush current 1.8 A
Operating frequency 50/60 Hz
Mains frequency 50/60 Hz
Max. lamp number on MCB B10 A 250
Max. lamp number on MCB B16 A 400
Power factor λ > 0.50

Photometrical data

Luminous flux 220 lm
Nominal useful luminous flux 90° 220 lm
Luminous efficacy 88 lm/W
Lumen main.fact.at end of nom.life time 0.70
Light color (designation) Warm Comfort Light
Color temperature 2400 K
Color rendering index Ra 80
Light color 824
Standard deviation of color matching ≤6 sdcm
Rated LLMF at 6,000 h 0.80
Flickering metric (Pst LM) ≤1
Stroboscope effect metric (SVM) ≤0.4

Light technical data

Beam angle 300 °
Warm-up time (60 %) ‹ 0.50 s
Starting time < 0.5 s

Dimensions & Weight

Overall length 105.00 mm
Diameter 60.00 mm
Maximum diameter 60 mm
Product weight 31.00 g

Temperatures & operating conditions

Ambient temperature range -20…+40 °C
Maximum temperature at tc test point 60 °C

Lifespan

Lifespan L70/B50 at 25 °C 15000 h
Number of switching cycles 100000
Lumen maintenance at end of service lifetime 0.70
Rated lamp survival factor at 6,000 h ≥ 0.90

Additional product data

Base (standard designation) E27
Mercury content 0.0 mg
Mercury-free Yes
Design / version Clear gold
Product remark All technical parameters apply to the entire lamp, Due to the complex production process for light-emitting diodes, the typical values shown for the technical LED parameters are purely statistical values that do not necessarily match the actual technical parameters of each individual product, which can vary from the typical value

Capabilities

Dimmable No

Certificates & Standards

Energy efficiency class F 1)
Energy consumption 3.00 kWh/1000h
Type of protection IP20
Standards CE, EAC
Photobiological safety group acc. to EN62778 RG0

1) Energy efficiency class (EEC) on a scale of A (highest efficiency) to G (lowest efficiency)

Country-specific categorizations

Order reference 1906LEDCLA222,5

LOGISTICAL DATA

Temperature range at storage -20…+80 °C

Energy labelling regulation data acc EU 2019/2015

Lighting technology used LED
Non-directional or directional NDLS
Mains or non-mains MLS
Light source cap-type (or other electric interface) E27
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Standby power 0 W
Claim of equivalent power Yes
Length 105.00 mm
Height 60.00 mm
Width 60.00 mm
Chromaticity coordinate x 0.494
Chromaticity coordinate y 0.424
R9 Colour rendering index 0.00
Beam angle correspondence SPHERE_360
Survival factor 0.90
Displacement factor ≥0.4
LED light source replaces a fluorescent light source No
EPREL ID 1402988,523096
Model number AC32435,AC17517,AC32435

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals Contains at least 10 mg
Quantity of rare earths Contains at least 1 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Lower energy consumption than incandescent or halogen lamps
  • Instant 100 % light, no warm-up time
  • Can be easily fitted instead of ordinary light bulbs
  • Lamps with innovative LED "filament" technology
Areas of application
  • Perfect for decorative installations
  • Domestic applications
  • General illumination
  • Outdoor use in suitable outdoor luminaires only
Product features
  • LED lamps for line voltage
  • Lamp made of glass
  • Lifetime up to 15,000 h
  • Beam angle: up to 360°
  • Good quality of light; color rendering index Ra: ≥ 80; constant chromaticity
Safety advice
  • Do not touch the lamp if broken.
  • Must not be used if outer bulb is defective.
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075293199 Folding box
1
61 mm x 61 mm x 144 mm 45.00 g 0.54 dm³
4058075290754 Shipping box
10
317 mm x 132 mm x 158 mm 602.00 g 6.61 dm³
4058075606463 Shipping box
6
195 mm x 140 mm x 156 mm 360.00 g 4.26 dm³
EAN SEG number STK number EFO number ELDAS number
4058075293199 8294895 4731259 3720554 941840610
