Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux | Claimed equiv. conventional lamp power | Beam angle | Dimmable |
|---|---|---|---|---|---|---|---|---|
| LED TUBE T8 18 EM PLASTIC 600 mm 6.6W 830 | G13 | 6.6 W | 220…240 V | 30000 h | 720 lm | 18 W | 190 ° | No |
| LED TUBE T8 18 EM PLASTIC 600 mm 6.6W 840 | G13 | 6.6 W | 220…240 V | 30000 h | 800 lm | 18 W | 190 ° | No |
| LED TUBE T8 18 EM PLASTIC 600 mm 6.6W 865 | G13 | 6.6 W | 220…240 V | 30000 h | 800 lm | 18 W | 190 ° | No |
| LED TUBE T8 36 EM PLASTIC 1200 mm 15W 830 | G13 | 15 W | 220…240 V | 30000 h | 1620 lm | 36 W | 190 ° | No |
| LED TUBE T8 36 EM PLASTIC 1200 mm 15W 840 | G13 | 15 W | 220…240 V | 30000 h | 1800 lm | 36 W | 190 ° | No |
| LED TUBE T8 36 EM PLASTIC 1200 mm 15W 865 | G13 | 15 W | 220…240 V | 30000 h | 1800 lm | 36 W | 190 ° | No |
| LED TUBE T8 58 EM PLASTIC 1500 mm 18.3W 830 | G13 | 18.3 W | 220…240 V | 30000 h | 2000 lm | 58 W | 190 ° | No |
| LED TUBE T8 58 EM PLASTIC 1500 mm 18.3W 840 | G13 | 18.3 W | 220…240 V | 30000 h | 2200 lm | 58 W | 190 ° | No |
| LED TUBE T8 58 EM PLASTIC 1500 mm 18.3W 865 | G13 | 18.3 W | 220…240 V | 30000 h | 2200 lm | 58 W | 190 ° | No |
| Nominal wattage | 18.3 W |
| Construction wattage | 18.30 W |
| Nominal voltage | 220…240 V |
| Operating mode | Conventional control gear (CCG), AC Mains |
| Nominal current | 90 mA |
| Type of current | AC |
| Inrush current | 11.6 A |
| Suitable for DC input | Yes |
| Input voltage DC | 186…260 V |
| Operating frequency | 50/60 Hz |
| Mains frequency | 50/60 Hz |
| Max. lamp number on MCB B10 A | 53 |
| Max. lamp number on MCB B10 A - CCG without compensation | 51 |
| Max. lamp number on MCB B10 A - CCG with compensation | 26 |
| Max. lamp number on MCB B16 A | 67 |
| Max. lamp number on MCB B16 A - CCG without compensation | 64 |
| Max. lamp number on MCB B16 A - CCG with compensation | 33 |
| Total harmonic distortion | < 52 % |
| Power factor λ | 0.90 |
| Luminous flux | 2200 lm |
| Luminous efficacy | 120 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Cool Daylight |
| Color temperature | 6500 K |
| Color rendering index Ra | 80 |
| Light color | 865 |
| Standard deviation of color matching | ≤6 sdcm |
| Rated LLMF at 6,000 h | 0.80 |
| Flickering metric (Pst LM) | 1 |
| Stroboscope effect metric (SVM) | 0.4 |
| Beam angle | 190 ° |
| Warm-up time (60 %) | ‹ 0.50 s |
| Starting time | < 0.5 s |
| Overall length | 1514.00 mm |
| Length with base excl. base pins/connection | 1500.00 mm |
| Diameter | 26.80 mm |
| Tube diameter | 25,8 mm |
| Maximum diameter | 28 mm |
| Product weight | 140.00 g |
| Ambient temperature range | -20…+45 °C 1) |
| Maximum temperature at tc test point | 70 °C |
1) Temperature surrounding the lamp - for enclosed luminaires: temperature inside of the luminaire
| Lifespan L70/B50 at 25 °C | 30000 h |
| Number of switching cycles | 200000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Rated lamp survival factor at 6,000 h | ≥ 0.90 |
| Base (standard designation) | G13 |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Dimmable | No |
| Energy efficiency class | E 1) |
| Energy consumption | 19.00 kWh/1000h |
| Type of protection | IP20 |
| Standards | CE, EAC, UKCA |
| Photobiological safety group acc. to EN62778 | RG0 |
1) Energy efficiency class (EEC) on a scale of A (highest efficiency) to G (lowest efficiency)
| Order reference | LEDTUBE T8 58 E |
| Temperature range at storage | -20…+80 °C |
| Lighting technology used | LED |
| Non-directional or directional | NDLS |
| Mains or non-mains | MLS |
| Light source cap-type (or other electric interface) | G13 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Standby power | <0.5 W |
| Claim of equivalent power | No |
| Length | 1514.00 mm |
| Height | 26.80 mm |
| Width | 26.80 mm |
| Chromaticity coordinate x | 0.313 |
| Chromaticity coordinate y | 0.337 |
| R9 Colour rendering index | 1 |
| Beam angle correspondence | SPHERE_360 |
| Survival factor | 0.9 |
| Displacement factor | 0.9 |
| LED light source replaces a fluorescent light source | No |
| EPREL ID | 1334028,1529797 |
| Model number | AC45435,AC51447 |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854039409 | Sleeve 1 |
27 mm x 27 mm x 1,610 mm | 242.00 g | 1.17 dm³ |
| 4099854039416 | Shipping box 8 |
1,655 mm x 143 mm x 100 mm | 2633.00 g | 23.67 dm³ |
