Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| Orbis Tube Bubble Glass 40CM Click CCT DIM IP44 Black | 9.00 W | 10000 | 120 ° | 820 lm | Yes |
| Orbis Tube Bubble Glass 40CM Click CCT DIM IP44 Chrome | 9.00 W | 10000 | 120 ° | 900 lm | Yes |
| Orbis Tube Bubble Glass 40CM Click CCT DIM IP44 White | 9.00 W | 10000 | 120 ° | 900 lm | Yes |
| Orbis Tube Bubble Glass 60CM Click CCT DIM IP44 Black | 12.00 W | 10000 | 120 ° | 1100 lm | Yes |
| Orbis Tube Bubble Glass 60CM Click CCT DIM IP44 White | 12.00 W | 10000 | 120 ° | 1200 lm | Yes |
| Orbis Tube Bubble Glass 60CM Click CCT DIM IP44 Chrome | 12.00 W | 10000 | 120 ° | 1200 lm | Yes |
| Nominal wattage | 9.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 70.000 mA |
| Inrush current | 0,07 A |
| Inrush current time Th50 | 192 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 52 |
| Max. number of luminaires per miniature circuit breaker C10 | 44 |
| Max. number of luminaires per miniature circuit breaker C16 | 71 |
| Power factor λ | > 0.5 |
| Total harmonic distortion | < 150 % |
| Protection class | II |
| Operating mode | External LED driver |
| Luminous flux | 820 lm |
| Total luminous flux of contained light sources | 1000 lm |
| Luminous efficacy | 91 lm/W |
| Color temperature | 3000 … 4000 K |
| Reference control setting of contained light source (Kelvin) | 3000 K |
| Light color (designation) | Warm White, Cool White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | 6 sdcm |
| Flickering metric (Pst LM) | < 1 |
| Stroboscope effect metric (SVM) | < 0.4 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Photobiological safety group acc. to EN62471 | RG0 |
| Beam angle | 120 ° |
| Length | 400.00 mm |
| Height | 54.00 mm |
| Width | 70.00 mm |
| Product weight | 500.00 g |
| Product color | Black |
| Housing color | Black |
| Body material | ABS/Polycarbonate (PC)/Aluminum |
| Cover material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+80 °C |
| Type of connection | Terminal, 2-Pole (L, N) |
| Type of protection | IP44 |
| Dimmable | Yes |
| Mounting type | Surface |
| Mounting location | Wall |
| Application environment | Indoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 10000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854279416 | Folding box 1 |
97 mm x 422 mm x 83 mm | 588.00 g | 3.40 dm³ |
| 4099854279423 | Shipping box 4 |
440 mm x 212 mm x 191 mm | 2767.00 g | 17.82 dm³ |
