Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| Orbis Ultra Slim Backlight Click-Dim 235mm Black 15W | 15.00 W | 25000 | 110 ° | 1020 lm | Yes |
| Orbis Ultra Slim Backlight Click-Dim 235mm White15W | 15.00 W | 25000 | 110 ° | 1100 lm | Yes |
| Orbis Ultra Slim Backlight Click-Dim 400mm Black 22W | 22.00 W | 25000 | 110 ° | 1740 lm | Yes |
| Orbis Ultra Slim Backlight Click-Dim 400mm White 22W | 22.00 W | 25000 | 110 ° | 1850 lm | Yes |
| Nominal wattage | 22.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 98.000 mA |
| Inrush current | 18 A |
| Inrush current time Th50 | 100 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 41 |
| Max. number of luminaires per miniature circuit breaker C16 | 53 |
| Power factor λ | > 0.90 |
| Total harmonic distortion | < 40 % |
| Protection class | II |
| Operating mode | Mains voltage |
| Luminous flux | 1850 lm |
| Total luminous flux of contained light sources | 2720 lm |
| Luminous efficacy | 84 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | ≤6 sdcm |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG0 |
| Photobiological safety group acc. to EN62471 | RG0 |
| Beam angle | 110 ° |
| UGR | < 25 |
| Diameter | 400.00 mm |
| Height | 27.00 mm |
| Product weight | 1065.00 g |
| Product color | White |
| Body material | Plastic |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Type of connection | Terminal, 2-pin |
| Type of protection | IP20 |
| Dimmable | Yes |
| Type of dimming | 3 DIM |
| Mounting type | Surface |
| Application environment | Indoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 25000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075752849 | Folding box 1 |
52 mm x 406 mm x 428 mm | 1186.00 g | 9.04 dm³ |
| 4058075752856 | Shipping box 5 |
417 mm x 275 mm x 444 mm | 6686.00 g | 50.92 dm³ |
| EAN | ELDAS number |
|---|---|
| 4058075752849 | 941320710 |
