Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| Orbis Plate Click Sensor 510mm 32W | 32.00 W | 15000 | 120 ° | 1800 lm | No |
| Orbis Sparkledot Click Sensor 340mm 24W | 24.00 W | 15000 | 120 ° | 1680 lm | No |
| Orbis Sparkledot Click Sensor 440mm 32W | 32.00 W | 15000 | 120 ° | 2250 lm | No |
| Orbis Square Click Sensor 430x430mm 50W | 50.00 W | 15000 | 120 ° | 3700 lm | No |
| Orbis Square Click Sensor 530x530mm 60W | 60.00 W | 15000 | 120 ° | 4450 lm | No |
| Nominal wattage | 32.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Power factor λ | > 0.70 |
| Protection class | II |
| Operating mode | Mains voltage |
| Luminous flux | 2250 lm |
| Total luminous flux of contained light sources | 4000 lm |
| Luminous efficacy | 70 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 6 sdcm |
| Beam angle | 120 ° |
| Diameter | 440.00 mm |
| Height | 75.00 mm |
| Product weight | 1050.00 g |
| Product color | White |
| Housing color | White |
| Body material | Steel |
| Cover material | Polymethylmethacrylate (PMMA) |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…40 °C |
| Type of connection | Push button terminal, 2-pole |
| Type of protection | IP20 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling |
| Application environment | Indoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Type of sensor | Light, Motion |
| Sensor technology | Microwave |
| Sensor controlled switching time | 5 s…30 min |
| Detection range of motion sensor | 2…6 m |
| Detection threshold of daylight sensor | 2…50 lx |
| Standards | CE, EAC, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075472891 | Folding box 1 |
487 mm x 92 mm x 492 mm | 1460.00 g | 22.04 dm³ |
| 4058075472907 | Shipping box 5 |
507 mm x 482 mm x 518 mm | 9008.00 g | 126.59 dm³ |
| EAN | ELDAS number |
|---|---|
| 4058075472891 | 941003430 |
