Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| Damp proof Essential Extrusion 18W 600mm 840 | 18.00 W | 15000 | 140 ° | 2160 lm | No |
| Damp proof Essential Extrusion 36W 1200mm 840 | 36.00 W | 15000 | 140 ° | 4320 lm | No |
| Damp proof Essential Extrusion 50W 1500mm 840 | 50.00 W | 15000 | 140 ° | 6000 lm | No |
| Nominal wattage | 18.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 140.000 mA |
| Inrush current | 17.6 A |
| Inrush current time Th50 | 23 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 42 |
| Max. number of luminaires per miniature circuit breaker C10 | 34 |
| Max. number of luminaires per miniature circuit breaker C16 | 54 |
| Power factor λ | ≥0.5 |
| Total harmonic distortion | < 150 % |
| Protection class | II |
| Operating mode | Integrated LED driver |
| Luminous flux | 2160 lm |
| Total luminous flux of contained light sources | 2250 lm |
| Luminous efficacy | 120 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | 5 sdcm |
| Flickering metric (Pst LM) | <1 |
| Stroboscope effect metric (SVM) | <0.4 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 140 ° |
| Length | 640.00 mm |
| Height | 47.70 mm |
| Width | 36.70 mm |
| Product weight | 208.00 g |
| Product color | White |
| Housing color | White |
| Body material | Polycarbonate (PC) |
| Cover material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+80 °C |
| Type of connection | Cable, 2-pole |
| Type of protection | IP65 |
| Protection class IK (shock resistance) | IK08 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Number of illuminants | Not relevant |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854287855 | Folding box 1 |
42 mm x 54 mm x 647 mm | 225.00 g | 1.47 dm³ |
| 4099854287862 | Shipping box 6 |
675 mm x 135 mm x 120 mm | 1668.00 g | 10.94 dm³ |
