Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| Decor Mesh Table 10W 830 Black | 10.00 W | 15000 | 110 ° | 640 lm | No |
| Decor Mesh Ceiling 18.5W 830 Black | 18.50 W | 15000 | 110 ° | 1130 lm | No |
| Decor Mesh Pendant 18.5W 830 Black | 18.50 W | 15000 | 110 ° | 1160 lm | No |
| Decor Mesh Floor 18.5W 830 Black | 18.50 W | 15000 | 100 ° | 1200 lm | No |
| Nominal wattage | 10.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 56.000 mA |
| Inrush current | 0.056 A |
| Inrush current time Th50 | 64 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 228 |
| Max. number of luminaires per miniature circuit breaker C10 | 142 |
| Max. number of luminaires per miniature circuit breaker C16 | 228 |
| Power factor λ | 0.70 |
| Total harmonic distortion | < 70 % |
| Protection class | II |
| Operating mode | Mains voltage |
| Luminous flux | 640 lm |
| Total luminous flux of contained light sources | 1000 lm |
| Luminous efficacy | 68.8 lm/W |
| Color temperature | 3000 K |
| Color rendering index Ra | 80 |
| Standard deviation of color matching | 6 sdcm |
| Flickering metric (Pst LM) | 0,7 |
| Stroboscope effect metric (SVM) | 0,25 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 110 ° |
| Diameter | 300.00 mm |
| Height | 403.00 mm |
| Product weight | 1340.00 g |
| Cable length | 1500 mm |
| Product color | Black |
| Housing color | Black |
| Body material | Steel|Rubberwood |
| Cover material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+80 °C |
| Type of connection | Plug type C (EU) |
| Type of protection | IP20 |
| Dimmable | No |
| Mounting type | Standing |
| Mounting location | Table |
| Adjustable | No |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE |
| Replaceable light source (EPREL) | Not replaceable |
| Product remark | Available from July 2025 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075847446 | Folding box 1 |
342 mm x 342 mm x 233 mm | 1794.00 g | 27.25 dm³ |
| 4058075847453 | Shipping box 4 |
944 mm x 358 mm x 368 mm | 8657.00 g | 124.37 dm³ |
