Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LED Sensor Batten 320mm 4W 3000K | 4.00 W | 100000 | 180 ° | 400 lm | No |
| LED Sensor Batten 600mm 8W 3000K | 8.00 W | 100000 | 180 ° | 800 lm | No |
| LED Sensor Batten 1200mm 14W 3000K | 14.00 W | 100000 | 180 ° | 1400 lm | No |
| Nominal wattage | 8.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 64.000 mA |
| Inrush current time Th50 | 420 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 17 |
| Max. number of luminaires per miniature circuit breaker C16 | 28 |
| Power factor λ | > 0.5 |
| Protection class | II |
| Operating mode | Integrated LED driver |
| Luminous flux | 800 lm |
| Total luminous flux of contained light sources | 900 lm |
| Luminous efficacy | 100 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 5 sdcm |
| Photobiological safety group acc. to EN62778 | RG0 |
| Photobiological safety group acc. to EN62471 | RG0 |
| Beam angle | 180 ° |
| Length | 573.00 mm |
| Height | 36.00 mm |
| Width | 28.00 mm |
| Product weight | 118.00 g |
| Product color | White |
| Housing color | White |
| Body material | Plastic |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Type of connection | Plug type C (EU) |
| Type of protection | IP20 |
| Dimmable | No |
| Mounting type | Surface |
| Application environment | Indoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
| Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Type of sensor | Movement |
| Standards | CE |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075762138 | Folding box 1 |
40 mm x 70 mm x 614 mm | 201.00 g | 1.72 dm³ |
| 4058075762145 | Shipping box 8 |
608 mm x 180 mm x 167 mm | 2055.00 g | 18.28 dm³ |
| EAN | ELDAS number |
|---|---|
| 4058075762138 | 941004200 |
