LUNETTA Round

Choose your product version

OVERVIEW

Product description Nominal wattage Luminous flux Dimmable
LUNETTA Round White 0.30 W 3 lm No


LUNETTA Round White

Product benefits
  • Automatically switches on and off according to the amount of available daylight
  • Plug and Play due to EU Plug
  • Energy-efficient thanks to LED technology

PRODUCT DETAILS

Electrical data

Nominal wattage 0.30 W
Nominal voltage 220…240 V
Mains frequency 50…60 Hz
Nominal current 30.000 mA
Max. number of luminaires per miniature circuit breaker C10 -
Protection class II
Operating mode Mains voltage

Photometrical data

Luminous flux 3 lm
Color temperature 3000 K
Light color (designation) Warm White
Color rendering index Ra ≥80
Photobiological safety group acc. to EN62778 RG1
Photobiological safety group acc. to EN62471 RG0

Dimensions & Weight

Diameter 71.00 mm
Height 60.00 mm
Product weight 35.00 g

Materials & Colors

Product color White
Housing color White
Body material Polycarbonate (PC)|Acrylonitrile butadiene styrene (ABS)
Cover material Polycarbonate (PC)
Light emitting surface material Plastic
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range -20…+40 °C
Type of connection Plug type C (EU)
Type of protection IP20
Protection class IK (shock resistance) IK03
Dimmable No
Mounting type Surface
Mounting location Socket
Application environment Indoor
With light source Yes

Lifespan

Lifespan L70/B50 at 25 °C 25000 h 1)

1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Certificates & Standards

Standards CE, EAC
Replaceable light source (EPREL) Not replaceable

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Automatically switches on and off according to the amount of available daylight
  • Plug and Play due to EU Plug
  • Energy-efficient thanks to LED technology
Areas of application
  • Bedrooms
  • Children's bedrooms
  • For indoor use only
Product features
  • Integrated day/night sensor
  • Integrated on/off switch
Safety advice
  • This product is not a toy. It should not be left unattended in the hands of children or operated by children.
  • Not designed as a replacement for conventional lighting in private household.
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075266827 Blister
1
61 mm x 140 mm x 195 mm 56.00 g 1.67 dm³
4058075266834 Shipping box
6
385 mm x 154 mm x 210 mm 509.00 g 12.45 dm³
EAN ELDAS number
4058075266827 941797970
