Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| Linear Turn Connect 35cm CCT DIM White | 6.00 W | 15000 | 110 ° | 380 lm | Yes |
| Linear Turn Connect 35cm CCT DIM Black | 6.00 W | 15000 | 110 ° | 380 lm | Yes |
| Linear Turn Connect 55cm CCT DIM Black | 10.00 W | 15000 | 110 ° | 620 lm | Yes |
| Nominal wattage | 10.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 75.000 mA |
| Inrush current | 9,2 A |
| Inrush current time Th50 | 45 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 81 |
| Max. number of luminaires per miniature circuit breaker C10 | 65 |
| Max. number of luminaires per miniature circuit breaker C16 | 104 |
| Power factor λ | ≥0.5 |
| Total harmonic distortion | 120 % |
| Protection class | II |
| Operating mode | Mains voltage |
| Luminous flux | 620 lm |
| Total luminous flux of contained light sources | 700 lm |
| Luminous efficacy | 64 lm/W |
| Color temperature | 3000…4000…6500 K |
| Light color (designation) | Warm White, Cool White, Daylight |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 6 sdcm |
| Flickering metric (Pst LM) | <1 |
| Stroboscope effect metric (SVM) | <0.4 |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 110 ° |
| Length | 557.00 mm |
| Height | 24.00 mm |
| Width | 60.00 mm |
| Product weight | 480.00 g |
| Cable length | 1500 mm |
| Product color | Black |
| Housing color | Black |
| Body material | Aluminum |
| Cover material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+80 °C |
| Type of connection | Plug type C (EU) |
| Type of protection | IP20 |
| Dimmable | Yes |
| Type of dimming | Push DIM |
| Mounting type | Surface |
| Mounting location | Wall, Cabinet undersides |
| Application environment | Indoor |
| Adjustable | Yes |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE |
| Luminaire with limited surface temperature, "D sign" | No |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075842403 | Folding box 1 |
42 mm x 72 mm x 603 mm | 612.00 g | 1.82 dm³ |
| 4058075842410 | Shipping box 8 |
618 mm x 160 mm x 195 mm | 5231.00 g | 19.28 dm³ |
