Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| ENDURA Flood 10 W 4000 K DG | 10.00 W | 15000 | 120 ° | 800 lm | No |
| ENDURA Flood 20 W 4000 K DG | 20.00 W | 15000 | 120 ° | 1700 lm | No |
| ENDURA Flood 30 W 4000 K DG | 30.00 W | 15000 | 120 ° | 2700 lm | No |
| ENDURA Flood 50 W 4000 K DG | 50.00 W | 15000 | 120 ° | 4500 lm | No |
| ENDURA Flood 100 W 4000 K DG | 100.00 W | 15000 | 120 ° | 8800 lm | No |
| ENDURA Flood 150 W 4000 K DG | 150.00 W | 15000 | 120 ° | 13200 lm | No |
| Nominal wattage | 10.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 46.000 mA |
| Max. number of luminaires per miniature circuit breaker B16 | 278 |
| Max. number of luminaires per miniature circuit breaker C16 | 278 |
| Power factor λ | > 0.90 |
| Protection class | I |
| Operating mode | ELECTRONIC CONTROL GEAR (ECG) |
| Luminous flux | 800 lm |
| Luminous efficacy | 80 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | 6 sdcm |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG1 |
| Beam angle | 120 ° |
| Length | 122.00 mm |
| Height | 33.00 mm |
| Width | 108.00 mm |
| Product weight | 280.00 g |
| Product color | Dark gray |
| Housing color | Dark gray |
| Body material | Aluminum |
| Cover material | Glass |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+45 °C |
| Temperature range at storage | -30…+70 °C |
| Type of connection | Cable, 3-pole |
| Type of protection | IP65 |
| Protection class IK (shock resistance) | IK06 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Wall |
| Application environment | Outdoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, EAC, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075206663 | Folding box 1 |
72 mm x 122 mm x 136 mm | 311.00 g | 1.19 dm³ |
| 4058075206670 | Shipping box 12 |
255 mm x 225 mm x 285 mm | 4047.00 g | 16.35 dm³ |
| EAN | ELDAS number |
|---|---|
| 4058075206663 | 941508080 |
