Endura Style solar Lunar

Choose your product version

OVERVIEW

Product description Nominal wattage Number of switching cycles Luminous flux Dimmable
ENDURA Style Solar Lunar Wall Sensor 4.5W 3000K 4.50 W 12500 300 lm No


ENDURA Style Solar Lunar Wall Sensor 4.5W 3000K

Product benefits
  • Easy and quick installation
  • Demand based lighting and energy saving thanks to motion and daylight sensor
  • High-quality materials

PRODUCT DETAILS

Electrical data

Nominal wattage 4.50 W
Nominal voltage 3,7 V
Nominal current 1160.000 mA
Protection class III

Photometrical data

Luminous flux 300 lm
Total luminous flux of contained light sources 500 lm
Luminous efficacy 66 lm/W
Color temperature 3000 K
Light color (designation) Warm White
Color rendering index Ra ≥80
Standard deviation of color matching 6 sdcm
Flickering metric (Pst LM) -
Stroboscope effect metric (SVM) -
Photobiological safety group acc. to EN62778 RG0

Dimensions & Weight

Length 160.00 mm
Height 83.00 mm
Width 231.00 mm
Product weight 375.00 g

Materials & Colors

Product color Black
Housing color Black
Body material Acrylonitrile butadiene styrene (ABS)
Glow Wire Test according to IEC 60695-2-12 650 °C
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range -20…+40 °C
Type of protection IP44
Dimmable No
Mounting type Surface
Application environment Outdoor
With light source Yes

Lifespan

Lifespan L70/B50 at 25 °C 25000 h 1)
Number of switching cycles 12500

1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Sensor

Type of sensor Motion, Daylight
Sensor detection angle 100 °
Sensor controlled switching time 30 s
Detection range of motion sensor 5…8 m
Detection threshold of daylight sensor 0…25 lx

BATTERY

Type of Battery Lithium ion
Battery size [GMS] 18650
Number of included batteries 1
Nominal voltage of battery 3.7 V
Nominal capacity of battery 2200 mAh
Battery charging time 6 h

Certificates & Standards

Standards CE, UKCA
Luminaire with limited surface temperature, "D sign" No
Ball shot safe No
Replaceable light source (EPREL) Not replaceable

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals Contains at least 10 mg
Quantity of rare earths Contains at least 1 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage Lead (7439-92-1)

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Easy and quick installation
  • Demand based lighting and energy saving thanks to motion and daylight sensor
  • High-quality materials
Areas of application
  • Outdoor use (IP44)
  • Garages
  • Building facades
Product features
  • Solar powered outdoor LED luminaire
  • PIR motion detector and daylight sensor
  • Color temperature: 3,000 K (Warm White)
  • Battery charging via solar panel
  • Adjustable luminaire head
Safety advice
  • If the battery compartment (if applicable) does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention.
  • Please avoid: Maximal ambient temperature: +35 °C. Replacement of a battery with an incorrect type that can defeat safeguard (for example, in the case of some lithium battery types). Altitude during operation: 2000 m. Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion.
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075766280 Folding box
1
170 mm x 170 mm x 95 mm 429.00 g 2.75 dm³
4058075766297 Shipping box
4
360 mm x 190 mm x 220 mm 2196.00 g 15.05 dm³
EAN ELDAS number
4058075766280 941004970
