Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| ENDURA Style UpDown 12W Dark Gray | 12.00 W | 15000 | 100 ° | 700 lm | No |
| ENDURA Style UpDown 12W Aluminium | 12.00 W | 15000 | 100 ° | 700 lm | No |
| ENDURA Style UpDown 12W White | 12.00 W | 15000 | 100 ° | 700 lm | No |
| Nominal wattage | 12.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 60.000 mA |
| Max. number of luminaires per miniature circuit breaker B16 | 26 |
| Max. number of luminaires per miniature circuit breaker C16 | 35 |
| Power factor λ | > 0.5 |
| Total harmonic distortion | ≤ 70 % |
| Protection class | I |
| Operating mode | Mains voltage |
| Luminous flux | 700 lm |
| Total luminous flux of contained light sources | 1050 lm |
| Luminous efficacy | 58 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | ≤6 sdcm |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 100 ° |
| UGR | < 22 |
| Length | 55.00 mm |
| Height | 160.00 mm |
| Width | 90.00 mm |
| Product weight | 480.00 g |
| Product color | White |
| Housing color | White |
| Body material | Aluminum |
| Cover material | Glass |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+85 °C |
| Type of connection | Screw terminal |
| Type of protection | IP44 |
| Protection class IK (shock resistance) | IK06 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Wall |
| Application environment | Outdoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 30000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, EAC, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Replaceable light source (EPREL) | Not replaceable |
| Number of illuminants | empty |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Additional info can be provided per individual request |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075214071 | Folding box 1 |
74 mm x 109 mm x 180 mm | 493.00 g | 1.45 dm³ |
| 4058075214088 | Shipping box 6 |
240 mm x 240 mm x 195 mm | 3133.00 g | 11.23 dm³ |
| EAN | ELDAS number |
|---|---|
| 4058075214071 | 941200450 |
