Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| ENDURA Style Plate Wall 12.5W Dark Grey | 12.00 W | 12500 | 108 ° | 600 lm | No |
| ENDURA Style Plate Wall Sensor 12.5W Dark Grey | 12.50 W | 12500 | 108 ° | 630 lm | No |
| ENDURA Style Plate Wall 12W Stainless Steel | 12.00 W | 12500 | 108 ° | 650 lm | No |
| ENDURA Style Plate Wall Sensor 12.5W Stainless Steel | 12.50 W | 12500 | 108 ° | 650 lm | No |
| Nominal wattage | 12.50 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 65.000 mA |
| Max. number of luminaires per miniature circuit breaker B16 | 40 |
| Max. number of luminaires per miniature circuit breaker C10 | 40 |
| Max. number of luminaires per miniature circuit breaker C16 | 70 |
| Power factor λ | ≥0.5 |
| Protection class | II |
| Operating mode | Mains voltage |
| Luminous flux | 630 lm |
| Total luminous flux of contained light sources | 1500 lm |
| Luminous efficacy | 48 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | < 6 sdcm |
| Flickering metric (Pst LM) | <1 |
| Stroboscope effect metric (SVM) | <0.4 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 108 ° |
| Length | 60.00 mm |
| Height | 283.00 mm |
| Width | 180.00 mm |
| Product weight | 720.00 g |
| Product color | Dark gray |
| Housing color | Dark gray |
| Body material | Stainless steel |
| Cover material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Ambient temperature range | -20…+40 °C |
| Type of connection | Terminal, 2-Pole (L, N) |
| Type of protection | IP44 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Wall |
| Application environment | Outdoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 25000 h 1) |
| Number of switching cycles | 12500 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Type of sensor | Light, Motion |
| Sensor technology | Passive infrared (PIR) |
| Sensor detection angle | 100 ° |
| Sensor controlled switching time | 10 s…4 min |
| Detection range of motion sensor | 5…8 m |
| Detection threshold of daylight sensor | 10…2000 lx |
| Standards | CE, UKCA |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Product remark | Available from June 2025 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854510151 | Folding box 1 |
65 mm x 185 mm x 290 mm | 796.00 g | 3.49 dm³ |
| 4099854510168 | Shipping box 4 |
310 mm x 280 mm x 205 mm | 3546.00 g | 17.79 dm³ |
