ENDURA CLASSIC POST

Choose your product version



ENDURA Classic Post Sensor Up E27

Product benefits
  • High flexibility in the choice of the light source thanks to E27 socket
  • Easy and quick installation

PRODUCT DETAILS

Electrical data

Nominal voltage 220…240 V
Mains frequency 50…60 Hz
Protection class I
Operating mode Mains voltage

Dimensions & Weight

Diameter 127.0 mm
Length 212.00 mm
Height 193.00 mm
Width 127.00 mm
Product weight 1120.00 g

Materials & Colors

Product color Steel
Housing color Steel
Body material Stainless steel
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range -20…+40 °C
Temperature range at storage -20…+85 °C
Type of connection Screw terminal
Type of protection IP44
Dimmable No
Mounting type Surface
Mounting location Wall
Application environment Outdoor
With light source No
Holder designation E27

Sensor

Type of sensor Motion, Light
Sensor technology Passive infrared (PIR)
Sensor detection angle 80 °
Sensor controlled switching time 5 s…5 min
Detection range of motion sensor 8 m
Detection threshold of daylight sensor 10…2000 lx

Certificates & Standards

Standards CE, EAC, UKCA

Additional product data

Product remark Maximum bulb wattage: 60 W
Number of illuminants 1

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals 0 mg
Quantity of rare earths 0 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • High flexibility in the choice of the light source thanks to E27 socket
  • Easy and quick installation
Areas of application
  • Outdoor use (IP44)
  • Building facades
  • Entrance lighting
  • Patios, balconies
  • Pathway lighting
  • Driveways
Product features
  • Stainless steel housing
  • Diffuser made of clear glass with hammer finish
  • Available with and without motion sensor
  • Available as wall and bollard luminaires
  • Suitable for smart applications thanks to compatibility with SMART+ lamps
Equipment / Accessories
  • Complete mounting and connecting accessories included
  • No light sources included
Safety advice
  • All electrical connections must be made by a qualified person.
  • Caution, risk of electric shock.
  • Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075206540 Folding box
1
141 mm x 239 mm x 242 mm 1346.00 g 8.16 dm³
4058075206557 Shipping box
4
500 mm x 257 mm x 300 mm 6034.00 g 38.55 dm³
EAN ELDAS number
4058075206540 941797930
