Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Luminous flux | Dimmable |
|---|---|---|---|---|
| ENDURA Style Cylinder Wall 6W | 6.00 W | 15000 | 360 lm | No |
| ENDURA Style Cylinder Wall Sensor 6W | 6.00 W | 15000 | 360 lm | No |
| ENDURA Style Cylinder Ceiling 6W | 6.00 W | 15000 | 360 lm | No |
| ENDURA Style Cylinder 50cm 6W | 6.00 W | 15000 | 360 lm | No |
| ENDURA Style Cylinder 80cm 6W | 6.00 W | 15000 | 360 lm | No |
| Nominal wattage | 6.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 40.000 mA |
| Max. number of luminaires per miniature circuit breaker B16 | 320 |
| Max. number of luminaires per miniature circuit breaker C16 | 320 |
| Power factor λ | > 0.5 |
| Total harmonic distortion | < 120 % |
| Protection class | II |
| Operating mode | Mains voltage |
| Luminous flux | 360 lm |
| Total luminous flux of contained light sources | 660 lm |
| Luminous efficacy | 60 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 6 sdcm |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG0 |
| UGR | < 25 |
| Diameter | 101.00 mm |
| Length | 102.0 mm |
| Height | 500.00 mm |
| Width | 102.0 mm |
| Product weight | 800.00 g |
| Product color | Steel |
| Housing color | Steel |
| Body material | Stainless steel |
| Cover material | Polycarbonate (PC) |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+85 °C |
| Type of connection | Screw terminal |
| Type of protection | IP44 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Wall |
| Application environment | Outdoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 40000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, EAC, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Replaceable light source (EPREL) | Not replaceable |
| Number of illuminants | empty |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Additional info can be provided per individual request |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075205376 | Folding box 1 |
114 mm x 114 mm x 520 mm | 995.00 g | 6.76 dm³ |
| 4058075205383 | Shipping box 2 |
535 mm x 125 mm x 240 mm | 2283.00 g | 16.05 dm³ |
| EAN | ELDAS number |
|---|---|
| 4058075205376 | 941259270 |
