ENDURA CLASSIC TRADITION ALU

Choose your product version



ENDURA Classic Tradition Up E27 Gold

Product benefits
  • High flexibility in the choice of the light source thanks to E27 socket
  • Easy and quick installation

PRODUCT DETAILS

Electrical data

Nominal voltage 220…240 V
Mains frequency 50…60 Hz
Protection class I
Operating mode Mains voltage

Photometrical data

Flickering metric (Pst LM) -
Stroboscope effect metric (SVM) -

Dimensions & Weight

Length 230.00 mm
Height 260.00 mm
Width 170.00 mm
Product weight 570.00 g

Materials & Colors

Product color Black/Gold
Housing color Black/Gold
Body material Aluminum
Glow Wire Test according to IEC 60695-2-12 650 °C
Mercury content 0.0 mg

Application & Mounting

Ambient temperature range -20…+40 °C
Temperature range at storage -20…+85 °C
Type of connection Screw terminal
Type of protection IP44
Dimmable No
Mounting type Surface
Mounting location Wall
Application environment Outdoor
With light source No
Holder designation E27

Certificates & Standards

Standards CE, EAC, UKCA
Luminaire with limited surface temperature, "D sign" No

Additional product data

Product remark Maximum bulb wattage: 60 W
Number of illuminants 1

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals 0 mg
Quantity of rare earths 0 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage No

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • High flexibility in the choice of the light source thanks to E27 socket
  • Easy and quick installation
Areas of application
  • Outdoor use (IP44)
  • Building facades
  • Entrance lighting
  • Patios, balconies
  • Pathway lighting
  • Driveways
Product features
  • Die-cast aluminum housing
  • Diffuser made of clear polycarbonate
  • Available with and without motion sensor
  • Available as wall and bollard luminaires
  • Suitable for smart applications thanks to compatibility with SMART+ lamps
Equipment / Accessories
  • Complete mounting and connecting accessories included
  • No light sources included
Safety advice
  • All electrical connections must be made by a qualified person.
  • Caution, risk of electric shock.
  • Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075206229 Folding box
1
181 mm x 239 mm x 292 mm 755.00 g 12.63 dm³
4058075206236 Shipping box
4
493 mm x 377 mm x 312 mm 3780.00 g 57.99 dm³
EAN ELDAS number
4058075206229 941259430
