Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LED Worklight S-Stand 20 W 4000 K | 20.00 W | 15000 | 120 ° | 1700 lm | No |
| LED Worklight S-Stand 30 W 4000 K | 30.00 W | 15000 | 120 ° | 2700 lm | No |
| LED Worklight S-Stand 50 W 4000 K | 50.00 W | 15000 | 120 ° | 4500 lm | No |
| Nominal wattage | 20.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 92.000 mA |
| Inrush current | 0,05 A |
| Max. number of luminaires per miniature circuit breaker C10 | - |
| Power factor λ | > 0.90 |
| Protection class | I |
| Operating mode | Electronic control gear (ECG) |
| Luminous flux | 1700 lm |
| Luminous efficacy | 85 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | 6 sdcm |
| Photobiological safety group acc. to EN62778 | RG1 |
| Photobiological safety group acc. to EN62471 | RG1 |
| Beam angle | 120 ° |
| Length | 180.00 mm |
| Height | 280.00 mm |
| Width | 160.00 mm |
| Product weight | 960.00 g |
| Product color | Dark gray |
| Housing color | Dark gray |
| Body material | Aluminum|Steel |
| Cover material | Glass |
| Light emitting surface material | Glass |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+45 °C |
| Temperature range at storage | -30…+70 °C |
| Type of connection | Protective contact Plug type |
| Type of protection | IP65 1) |
| Protection class IK (shock resistance) | IK06 |
| Dimmable | No |
| Mounting type | Standing |
| Mounting location | Floor |
| Application environment | Outdoor |
| Adjustable | Yes |
| With light source | Yes |
1) Luminaire head and housing IP65, plug IP44
| Lifespan L70/B50 at 25 °C | 25000 h 1) |
| Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, EAC |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075213838 | Folding box 1 |
81 mm x 181 mm x 245 mm | 1028.00 g | 3.59 dm³ |
| 4058075213845 | Shipping box 10 |
415 mm x 375 mm x 265 mm | 10872.00 g | 41.24 dm³ |
