PARATHOM DAYLIGHT SENSOR CLASSIC A

Choose your product version

40 4 W/4000 K E27

40 4 W/4000 K E27

60 6 W/4000 K E27

60 6.5 W/4000 K E27

7.3W 827 Clear E27

8.8W 827 Frosted E27

60 FR 9 W/2700 K E27

OVERVIEW

Product description Base (standard designation) Nominal wattage Nominal voltage Nominal lamp life time Nominal luminous flux Claimed equiv. conventional lamp power Beam angle Dimmable
P CLAS A 40 4 W/4000 K E27 E27 4 W 220…240 V 15000 h 470 lm 40 W 300 ° No
P PLUS DS CLAS A 40 4 W/4000 K E27 E27 4 W 220…240 V 15000 h 470 lm 40 W 300 ° No
P PLUS DS CLAS A 60 6 W/4000 K E27 E27 6 W 220…240 V 15000 h 806 lm 60 W 300 ° No
P CLAS A 60 6.5 W/4000 K E27 E27 6.5 W 220…240 V 15000 h 806 lm 60 W 300 ° No
LED Classic A 60 Filament P 7.3W 827 Clear E27 E27 7.3 W 220…240 V 15000 h 806 lm 60 W 320 ° No
LED Star Classic A 60 Filament Daylight Sensor 8.8W 827 Frosted E27 E27 8.8 W 220…240 V 25000 h 806 lm 60 W 200 ° No
PCLAS 60DS FR 60 FR 9 W/2700 K E27 E27 9 W 220…240 V 25000 h 806 lm 60 W 240 ° No


LED Classic A 40 Filament P 4.9W 827 Clear E27

Product benefits
  • Short payback period thanks to low energy consumption and maintenance costs
  • Energy-saving lighting solution thanks to automatic switch off at daylight
  • Safety through automatic switch-on at darkness
  • Low energy consumption
  • Easy replacement of classic lamps thanks to compact design
  • Instant 100 % light, no warm-up time
  • Light sensors detect daylight on the basis of the spectral distribution
View all details
Product data sheet
Go to LEDVANCE successor product

PRODUCT DETAILS

Electrical data

Nominal wattage 4.9 W
Construction wattage 4.90 W
Nominal voltage 220…240 V
Operating mode AC Mains
Claimed equiv. conventional lamp power 40 W
Nominal current 40 mA
Type of current AC
Inrush current 4.22 A
Operating frequency 50/60 Hz
Mains frequency 50/60 Hz
Max. lamp number on MCB B10 A 29
Max. lamp number on MCB B16 A 47
Total harmonic distortion 150 %
Power factor λ > 0.40

Photometrical data

Luminous flux 470 lm
Nominal useful luminous flux 90° 470 lm
Luminous efficacy 95 lm/W
Lumen main.fact.at end of nom.life time 0.93
Light color (designation) Warm White
Color temperature 2700 K
Color rendering index Ra 80
Light color 827
Standard deviation of color matching ≤6 sdcm
Rated LLMF at 6,000 h 0.80
Flickering metric (Pst LM) 1,0
Stroboscope effect metric (SVM) 0,4

Light technical data

Beam angle 320 °
Warm-up time (60 %) ‹ 0.50 s
Starting time < 0.5 s

Dimensions & Weight

Overall length 106.00 mm
Diameter 60.00 mm
Maximum diameter 60 mm
Product weight 32.00 g

Temperatures & operating conditions

Ambient temperature range -20…40 °C
Maximum temperature at tc test point 80 °C

Lifespan

Lifespan L70/B50 at 25 °C 15000 h
Number of switching cycles 100000
Lumen maintenance at end of service lifetime 0.93
Rated lamp survival factor at 6,000 h ≥ 0.90

Additional product data

Base (standard designation) E27
Mercury content 0.0 mg
Design / version Clear

Capabilities

Dimmable No

Certificates & Standards

Energy efficiency class F
Energy consumption 5.00 kWh/1000h
Type of protection IP20
Standards CE, EAC
Photobiological safety group acc. to EN62778 RG1

Country-specific categorizations

Order reference LEDPCLA40DS 4,9

Energy labelling regulation data acc EU 2019/2015

Lighting technology used LED
Non-directional or directional NDLS
Mains or non-mains MLS
Light source cap-type (or other electric interface) E27
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Standby power <0,5 W
Networked standby power for CLS not applicable
Claim of equivalent power Yes
Length 106.00 mm
Height 60.00 mm
Width 60.00 mm
Chromaticity coordinate x 0.463
Chromaticity coordinate y 0.420
R9 Colour rendering index 0.00
Beam angle correspondence SPHERE_360
Survival factor 0,9
Displacement factor 0,6
LED light source replaces a fluorescent light source No
EPREL ID 1206270
Model number AC41849

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage Lead (7439-92-1)

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Short payback period thanks to low energy consumption and maintenance costs
  • Energy-saving lighting solution thanks to automatic switch off at daylight
  • Safety through automatic switch-on at darkness
  • Low energy consumption
  • Easy replacement of classic lamps thanks to compact design
  • Instant 100 % light, no warm-up time
  • Light sensors detect daylight on the basis of the spectral distribution
Areas of application
  • Wherever constant lighting is necessary at night
  • Outdoor use in suitable outdoor luminaires only
Product features
  • LED alternative to conventional lamps
  • Not dimmable
  • Good quality of light; color rendering index Ra: ≥ 80; constant chromaticity
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075761995 Folding box
1		 60 mm x 60 mm x 111 mm 46.00 g 0.40 dm³
4058075762008 Shipping box
10		 315 mm x 131 mm x 126 mm 554.00 g 5.20 dm³
Declarations of conformity
Classic A lamp PDF (309.4 KB)
Product image: white background, diagonal
LEDSCLA60DS 7,3W/827 2 30VFILE27 4X1OSRAM JPG (370.14 KB)
Product image: white background, upright
LEDSCLA60DS 7,3W/827 2 30VFILE27 4X1OSRAM JPG (341.13 KB)
Combo Shot = Product Beauty Shot + Packaging Image
PARA PLUS DAYLIGHT SEN SOR CLA 40 4.9W 827 FI L E27 MiCh JPG (1.54 MB)
Packaging image, frontal
PARA PLUS DAYLIGHT SEN SOR CLA 40 4.9W 827 FI L E27 MiCh JPG (2.67 MB)
Packaging image, spacial
PARA PLUS DAYLIGHT SEN SOR CLA 40 4.9W 827 FI L E27 MiCh JPG (2.24 MB)
Energy label
EL-4058075761995-AC418 49 PDF (21.43 KB)
Logos and pictos
F left SVG (1.83 KB)
Logos and pictos
F left BW SVG (1.07 KB)
Logos and pictos
F right SVG (1.81 KB)
Logos and pictos
F right BW SVG (1.06 KB)
Spectral power distribution
EPREL data spectral di agram PROF LEDr 2700K PNG (103.24 KB)
EAN SEG number STK number EFO number ELDAS number
4058075761995 8298038 4731862 3764976 941812810
