Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Luminous flux | Dimmable |
|---|---|---|---|---|
| EM EXIT E 0.7W 30M 3H EM/AC AT | 0.70 W | 50000 | 20 lm | No |
| Nominal wattage | 0.70 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50/60 Hz |
| Nominal current | 34.000 mA |
| Inrush current | 6,5 A |
| Inrush current time Th50 | 2.8 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 115 |
| Max. number of luminaires per miniature circuit breaker C10 | 92 |
| Max. number of luminaires per miniature circuit breaker C16 | 147 |
| Power factor λ | 0.25 |
| Protection class | II |
| Operating mode | Integrated LED driver |
| Luminous flux | 20 lm |
| Luminous efficacy | 25 lm/W |
| Color temperature | 5700 K |
| Light color (designation) | Cool Daylight |
| Color rendering index Ra | > 70 |
| Low flicker | Yes |
| Flickering metric (Pst LM) | ≤ 1 |
| Stroboscope effect metric (SVM) | ≤ 0,4 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Length | 313.00 mm |
| Height | 42.00 mm |
| Width | 212.00 mm |
| Product weight | 510.00 g |
| Product color | White |
| Housing color | White |
| Body material | Polycarbonate (PC)|Polymethylmethacrylate (PMMA) |
| Cover material | Polycarbonate (PC)/Polymethylmethacrylate (PMMA) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | 0…+45 °C |
| Temperature range at storage | 0…+35 °C |
| Type of connection | Terminal |
| Type of protection | IP20 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling, Wall |
| Application environment | Indoor |
| Mounting depth | 0 mm |
| Adjustable | No |
| With light source | Yes |
| Number of switching cycles | 50000 |
| Output current | 260 mA |
| ECG - Output ripple current | 8 % |
| Type of Battery | LiFePO4 |
| Battery size [GMS] | Others |
| Nominal voltage of battery | 3,2 V |
| Nominal capacity of battery | 1100 mAh |
| Battery charging time | 24 h |
| Area of emergency application | Emergency exit signage |
| Type of emergency light operation | Maintained, Non-maintained |
| Type of emergency operation test | Automatic |
| Wattage in emergency operation mode | 0.7 W |
| Luminous flux in emergency operation mode | 20 lm |
| Battery life in emergency operation mode | 3 h |
| Integrated test switch | Yes |
| Standards | CE, CB, EAC, UKCA, ENEC |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Product remark | Available from March 2025 |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | 2-(2H-benzotriazol-2-yl)-4-(1,1,3,3-tetramethylbutyl)phenol (3147-75-9) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854230714 | Folding box 1 |
218 mm x 45 mm x 317 mm | 630.00 g | 3.11 dm³ |
| 4099854230721 | Shipping box 10 |
330 mm x 275 mm x 450 mm | 6780.00 g | 40.84 dm³ |
| Product image | Product name | EAN |
|---|---|---|
|
EM EXIT PICTO BLANK | 4099854261374 |
|
EM EXIT PICTO LEFT RIGHT | 4099854261336 |
|
EM EXIT PICTO UP | 4099854261350 |
|
EM EXIT PICTO DOWN | 4099854261312 |
| Product image | Product name | EAN |
|---|---|---|
|
EM EXIT FLAG KIT | 4099854232145 |
|
EM EXIT RECESSED KIT | 4099854232121 |
|
EM EXIT SUSPENSION KIT | 4099854232169 |
