VIALOX NAV-E SUPER 4Y

Choose your product version

50 W SUPER 4Y

70 W SUPER 4Y

100 W SUPER 4Y

150 W SUPER 4Y

250 W SUPER 4Y

400 W SUPER 4Y

OVERVIEW

Product description Base (standard designation) Nominal wattage Nominal voltage Nominal lamp life time Nominal luminous flux Dimmable
NAV-E 50 W SUPER 4Y E27 50 W 86 V 28000 h 4000 lm Yes
NAV-E 70 W SUPER 4Y E27 70 W 90 V 28000 h 6600 lm Yes
NAV-E 100 W SUPER 4Y E40 100 W 100 V 32000 h 10100 lm Yes
NAV-E 150 W SUPER 4Y E40 150 W 100 V 32000 h 17000 lm Yes
NAV-E 250 W SUPER 4Y E40 250 W 100 V 32000 h 31600 lm Yes
NAV-E 400 W SUPER 4Y E40 400 W 105 V 32000 h 56500 lm Yes


NAV-E 250 W SUPER 4Y

Product benefits
  • Very high luminous efficacy
  • Very good luminous flux maintenance throughout the life of the lamp
  • Energy savings of up to 50 % when replacing mercury vapor lamps (HQL)
  • Optimum energy efficiency on POWERTRONIC® PTo 3DIM ECGs
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 250 W
Construction wattage 262.70 W
Nominal voltage 100 V
Ignition voltage 3.3/5.0 kVp 1)
Operating mode Conventional control gear (CCG) and ignitor, Electronic control gear (ECG)
Nominal current 2.95 A
PFC capacitor at 50 Hz 32 µF

1) Minimum / Maximum

Photometrical data

Luminous flux 31600 lm
Luminous efficacy 120 lm/W
Color temperature 2000 K
Color rendering index Ra ≤25
Light color 220
Rated LLMF at 2,000 h 0.98
Rated LLMF at 4,000 h 0.97
Rated LLMF at 6,000 h 0.96
Rated LLMF at 8,000 h 0.95
Rated LLMF at 12,000 h 0.94
Rated LLMF at 16,000 h 0.94
Rated LLMF at 20,000 h 0.94
UV protection No

Dimensions & Weight

Overall length 226.00 mm
Diameter 91 mm
Product weight 200.00 g

Temperatures & operating conditions

Maximum permitted outer bulb temperature 400 °C
Maximum permitted base edge temperature 250 °C

Lifespan

Rated lamp survival factor at 2,000 h 0.99
Rated lamp survival factor at 4,000 h 0.99
Rated lamp survival factor at 6,000 h 0.98
Rated lamp survival factor at 8,000 h 0.98
Rated lamp survival factor at 12,000 h 0.97
Rated lamp survival factor at 16,000 0.96
Rated lamp survival factor at 20,000 h 0.95
Lifespan B10 24000 h
Lifespan B5 20000 h
Lifespan B50 36000 h

Additional product data

Base (standard designation) E40
Mercury content 21.6 mg
Design / version Coated
Product remark Important: Before replacing for NAV Standard lamps in existing installations, check that the igniters are suitable

Capabilities

Dimmable Yes 1)
Burning position Any
Enclosed luminaire required No

1) In combination with POWERTRONIC PTo

Certificates & Standards

Energy efficiency class E
Energy consumption 262.00 kWh/1000h

Country-specific categorizations

ILCOS SE-250-H/E/SL-E40-91/226
Order reference NAV-E 250W SUPE

Energy labelling regulation data acc EU 2019/2015

Lighting technology used HPS
Non-directional or directional NDLS
Mains or non-mains NMLS
Light source cap-type (or other electric interface) E40
Connected light source (CLS) No
Color-tuneable light source No
Envelope SECOND
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Claim of equivalent power No
Length 226.00 mm
Height 91 mm
Width 91 mm
Chromaticity coordinate x 0,535
Chromaticity coordinate y 0,420
Beam angle correspondence SPHERE_360
EPREL ID 546585
Model number AC34377,AC34377

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals 0 mg
Quantity of rare earths 0 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage Additional info can be provided per individual request
List of substances of very high concern in concentrations greater than 0.1% in mass percentage

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Very high luminous efficacy
  • Very good luminous flux maintenance throughout the life of the lamp
  • Energy savings of up to 50 % when replacing mercury vapor lamps (HQL)
  • Optimum energy efficiency on POWERTRONIC® PTo 3DIM ECGs
Areas of application
  • Streets
  • Outdoor lighting
  • Industrial installations
  • Suitable for use in open and enclosed luminaires
  • Outdoor applications only in suitable luminaires
Product features
  • Lamp survival factor: 95 % after 16,000 h burning time
  • Lamp maintenance factor: ≥ 80 % after 16,000 h burning time (according to DIN 13201)
  • Service lifetime: 4 years (at approx. 11 h/day)
  • Dimmable on conventional control gears and electronic control gears
Safety advice
  • Disconnect mains before installation.
  • Must not be used if outer bulb is defective.
  • Protect from spray water.
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4050300024387 Round wrap
1		 95 mm x 95 mm x 240 mm 198.00 g 2.17 dm³
4050300631868 Shipping box
12		 426 mm x 331 mm x 252 mm 2963.00 g 35.53 dm³
Declarations of conformity
EC Declaration of Conf ormity - 2021 9C1-4077 887-EN-00 - HPS PDF (42.71 KB)
Certificates
EAC RU C-DE.AYA46.B.85 891 29.06.2018-28.06.2 023 ROSTEST-Moskva - H PS PDF (3.21 MB)
Certificates
EAC N RU D-DE.MU62.B.0 0936_20 06.03.2020-05. 03.2025 Prommash Test - HPS PDF (1.13 MB)
Product image: white background, diagonal
324457_MERCURY VAPOUR LAMPS HQL DE LUXE HQL STANDARD TIF (21.43 MB)
Product line drawing with letters
2015_HIGH PRESSURE SOD IUM LAMPS VIALOX NAV-E / NAV-E SUPER 4Y SVG (7.64 KB)
Product line drawing, front, no dimensions
325819_VIALOX NAV-E SU PER 4Y E40 SVG (5.97 KB)
Energy label
EL-4050300024387-AC343 77 PDF (21.73 KB)
Logos and pictos
E left SVG (1.9 KB)
Logos and pictos
E left BW SVG (1.07 KB)
Logos and pictos
E right SVG (1.86 KB)
Logos and pictos
E right BW SVG (1.07 KB)
Spectral power distribution
384084_NAV_SUPER_4Y PNG (92.92 KB)
EAN SEG number STK number EFO number ELDAS number
4050300024387 8331608 4835584 3852135 948611580
