OVERVIEW

Product description	Base (standard designation)	Nominal wattage	Nominal voltage	Nominal lamp life time	Nominal luminous flux	Claimed equiv. conventional lamp power	Beam angle	Dimmable
LED TUBE T5 EXTERNAL HE14 P 549 mm 7.3W 830	G5	7.3 W	21 V	75000 h	1000 lm	14 W	180 °	Yes
LED TUBE T5 EXTERNAL HE14 P 549 mm 7.3W 840	G5	7.3 W	21 V	75000 h	1100 lm	14 W	180 °	Yes
LED TUBE T5 EXTERNAL HE14 P 549 mm 7.3W 865	G5	7.3 W	21 V	75000 h	1100 lm	14 W	180 °	Yes
LED TUBE T5 EXTERNAL HE21 P 849 mm 10.5W 830	G5	10.5 W	21 V	75000 h	1450 lm	21 W	180 °	Yes
LED TUBE T5 EXTERNAL HE21 P 849 mm 10.5W 840	G5	10.5 W	21 V	75000 h	1600 lm	21 W	180 °	Yes
LED TUBE T5 EXTERNAL HE21 P 849 mm 10.5W 865	G5	10.5 W	21 V	75000 h	1600 lm	21 W	180 °	Yes
LED TUBE T5 EXTERNAL HE28 P 1149 mm 16W 830	G5	16 W	41 V	75000 h	2160 lm	28 W	180 °	Yes
LED TUBE T5 EXTERNAL HE28 P 1149 mm 16W 840	G5	16 W	41 V	75000 h	2400 lm	28 W	180 °	Yes
LED TUBE T5 EXTERNAL HE28 P 1149 mm 16W 865	G5	16 W	41 V	75000 h	2400 lm	28 W	180 °	Yes
LED TUBE T5 EXTERNAL HE35 P 1449 mm 18W 830	G5	18 W	41 V	50000 h	2550 lm	35 W	180 °	Yes
LED TUBE T5 EXTERNAL HE35 P 1449 mm 18W 840	G5	18 W	41 V	50000 h	2800 lm	35 W	180 °	Yes
LED TUBE T5 EXTERNAL HE35 P 1449 mm 18W 865	G5	18 W	41 V	50000 h	2800 lm	35 W	180 °	Yes
LED TUBE T5 EXTERNAL HO24 P 549 mm 10.5W 830	G5	10.5 W	21 V	75000 h	1450 lm	24 W	180 °	Yes
LED TUBE T5 EXTERNAL HO24 P 549 mm 10.5W 840	G5	10.5 W	21 V	75000 h	1600 lm	24 W	180 °	Yes
LED TUBE T5 EXTERNAL HO24 P 549 mm 10.5W 865	G5	10.5 W	21 V	75000 h	1600 lm	24 W	180 °	Yes
LED TUBE T5 EXTERNAL HO39 P 849 mm 17W 830	G5	17 W	43 V	75000 h	2350 lm	39 W	180 °	Yes
LED TUBE T5 EXTERNAL HO39 P 849 mm 17W 840	G5	17 W	43 V	75000 h	2600 lm	39 W	180 °	Yes
LED TUBE T5 EXTERNAL HO39 P 849 mm 17W 865	G5	17 W	43 V	75000 h	2600 lm	39 W	180 °	Yes
LED TUBE T5 EXTERNAL HO49 P 1449 mm 26W 830	G5	26 W	42 V	50000 h	3600 lm	49 W	180 °	Yes
LED TUBE T5 EXTERNAL HO49 P 1449 mm 26W 840	G5	26 W	42 V	50000 h	4000 lm	49 W	180 °	Yes
LED TUBE T5 EXTERNAL HO49 P 1449 mm 26W 865	G5	26 W	42 V	50000 h	4000 lm	49 W	180 °	Yes
LED TUBE T5 EXTERNAL HO54 P 1149 mm 26W 830	G5	26 W	42 V	50000 h	3600 lm	54 W	180 °	Yes
LED TUBE T5 EXTERNAL HO54 P 1149 mm 26W 840	G5	26 W	42 V	50000 h	4000 lm	54 W	180 °	Yes
LED TUBE T5 EXTERNAL HO54 P 1149 mm 26W 865	G5	26 W	42 V	50000 h	4000 lm	54 W	180 °	Yes
LED TUBE T5 EXTERNAL HO80 P 1449 mm 37W 830	G5	37 W	42 V	50000 h	5050 lm	80 W	180 °	Yes
LED TUBE T5 EXTERNAL HO80 P 1449 mm 37W 840	G5	37 W	42 V	50000 h	5600 lm	80 W	180 °	Yes
LED TUBE T5 EXTERNAL HO80 P 1449 mm 37W 865	G5	37 W	42 V	50000 h	5600 lm	80 W	180 °	Yes

LED TUBE T5 EXTERNAL HO49 P 1449 mm 26W 840

Product benefits

Simple upgrade to dimmable LED system
Hassle free application, no ballast compatibility check necessary
Suitable for emergency lighting (self-contained battery pack)
Shatter protection thanks to special PET coating
No bending thanks to glass tube
5 years guarantee

View all details

Product data sheet

PRODUCT DETAILS

Technical data

Electrical data

Nominal wattage	26 W
Construction wattage	26.00 W
Nominal voltage	42 V
Operating mode	EXT ¹⁾
Nominal current	600 mA
Type of current	DC
Operating frequency	0 Hz
Mains frequency	0 Hz
Total harmonic distortion	< 20 %
Power factor λ	0.90

¹⁾ Designed to power with LEDVANCE LED DRIVER LED TUBE EXTERNAL DALI P

Photometrical data

Luminous flux	4000 lm
Luminous efficacy	154 lm/W
Lumen main.fact.at end of nom.life time	0.70
Light color (designation)	Cool White
Color temperature	4000 K
Color rendering index Ra	80
Light color	840
Standard deviation of color matching	≤5 sdcm
Rated LLMF at 6,000 h	0.80
Flickering metric (Pst LM)	<1
Stroboscope effect metric (SVM)	<0,4

Light technical data

Beam angle	180 °
Warm-up time (60 %)	‹ 2.00 s
Starting time	< 1.0 s

Dimensions & Weight

Overall length	1463.00 mm
Length with base excl. base pins/connection	1449.00 mm
Diameter	17.00 mm
Tube diameter	15,7 mm
Maximum diameter	17 mm
Product weight	137.00 g

Temperatures & operating conditions

Ambient temperature range	-20…+50 °C ¹⁾
Maximum temperature at tc test point	75 °C
Performance temp. acc. to IEC 62717

¹⁾ Temperature surrounding the lamp - for enclosed luminaires: temperature inside of the luminaire

Lifespan

Lifespan L70/B50 at 25 °C	50000 h
Number of switching cycles	200000
Lumen maintenance at end of service lifetime	0.70
Rated lamp survival factor at 6,000 h	≥ 0.90

Additional product data

Base (standard designation)	G5
Mercury content	0.0 mg
Mercury-free	Yes
Product remark	Single sided LED TUBE (one-sided DC input ) complying with safety requirement acc. IEC 62776:2014. Safety protection against electrical shock in misuse (ECG/CCG/Mains operation).

Capabilities

Dimmable

Yes

Certificates & Standards

Energy efficiency class	D ¹⁾
Energy consumption	26.00 kWh/1000h
Type of protection	IP20
Standards	CE, UKCA
Photobiological safety group acc. to EN62778	RG0

¹⁾ Energy efficiency class (EEC) on a scale of A (highest efficiency) to G (lowest efficiency)

Country-specific categorizations

Order reference

LEDTUBE T5 EXT

LOGISTICAL DATA

Temperature range at storage

-20…+80 °C

Energy labelling regulation data acc EU 2019/2015

Lighting technology used	LED
Non-directional or directional	NDLS
Mains or non-mains	NMLS
Light source cap-type (or other electric interface)	G5
Connected light source (CLS)	No
Color-tuneable light source	No
Envelope	No
High luminance light source	No
Anti-glare shield	No
Correlated colour temperature type	SINGLE_VALUE
Standby power	0 W
Claim of equivalent power	No
Length	1463.00 mm
Height	17.00 mm
Width	17.00 mm
Chromaticity coordinate x	0,381
Chromaticity coordinate y	0,379
R9 Colour rendering index	0.00
Beam angle correspondence	SPHERE_360
Survival factor	0,90
Displacement factor	0,90
LED light source replaces a fluorescent light source	No
EPREL ID	1161817
Model number	AC39944,AC39944

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals	Contains at least 10 mg
Quantity of rare earths	Contains at least 1 mg
Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage	Lead (7439-92-1)

¹⁾ According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product description

Product benefits

Simple upgrade to dimmable LED system
Hassle free application, no ballast compatibility check necessary
Suitable for emergency lighting (self-contained battery pack)
Shatter protection thanks to special PET coating
No bending thanks to glass tube
5 years guarantee

Areas of application

Industrial lighting (e.g. manufacturing plants, logistic centers, warehouses)
Linear lighting for office, education, storage areas and retail
Shops, supermarkets

Product features

Designed to power only with LED DRIVER LED TUBE EXTERNAL DALI
Lamp tube made of glass with splinter protection
Quality dimming of 1…100 %
High resistance to switching loads
Suitable for ambient temperatures from -20…+50 °C

Safety advice

Operation in outdoor applications in suitable damp-proof luminaires possible according to data sheet and installation instruction.
The operating temperature range of LED tube is restricted. In case of doubt regarding suitability of the application please measure Tc temperature on the product prior to installation.
LED TUBE T5 EXTERNAL HO80 cannot be operated with 2-channel driver.
All electrical connections must be made by a qualified person.
Disconnect mains before installation.

References / Links

For current information see www.ledvance.com/ledtube

GTIN and Packaging information

Product code	Packaging unit (Pieces/Unit)	Dimensions (length x width x height)	Gross weight	Volume
4058075730434	Sleeve 1	1,465 mm x 20 mm x 20 mm	159.00 g	0.59 dm³
4058075730441	Shipping box 25	1,522 mm x 152 mm x 175 mm	5300.00 g	40.49 dm³

Country-specific information

EAN	SEG number	STK number	EFO number	ELDAS number
4058075730434	8297876	4933229	3755210	941813330
