OVERVIEW

Product description	Base (standard designation)	Nominal wattage	Nominal voltage	Nominal lamp life time	Nominal luminous flux	Claimed equiv. conventional lamp power	Beam angle	Dimmable
SubstiTUBE T5 HF HE14 7 W/3000 K 549 mm	G5	7 W	40…70 V	50000 h	900 lm	14 W	190 °	No
SubstiTUBE T5 HF HE14 7 W/4000 K 549 mm	G5	7 W	40…70 V	50000 h	1000 lm	14 W	190 °	No
SubstiTUBE T5 HF HE14 7 W/6500 K 549 mm	G5	7 W	40…70 V	50000 h	1000 lm	14 W	190 °	No
SubstiTUBE T5 HF HE21 10 W/3000 K 849 mm	G5	10 W	50…80 V	50000 h	1350 lm	21 W	190 °	No
SubstiTUBE T5 HF HE21 10 W/4000 K 849 mm	G5	10 W	50…80 V	50000 h	1500 lm	21 W	190 °	No
SubstiTUBE T5 HF HE21 10 W/6500 K 849 mm	G5	10 W	50…80 V	50000 h	1500 lm	21 W	190 °	No
SubstiTUBE T5 HF HE28 17 W/3000 K 1163 mm	G5	17 W	100…130 V	50000 h	2150 lm	28 W	190 °	No
SubstiTUBE T5 HF HE28 17 W/4000 K 1163 mm	G5	17 W	100…130 V	50000 h	2400 lm	28 W	190 °	No
SubstiTUBE T5 HF HE28 17 W/6500 K 1163 mm	G5	17 W	100…130 V	50000 h	2400 lm	28 W	190 °	No
SubstiTUBE T5 HF HE35 18 W/3000 K 1463 mm	G5	18 W	105…150 V	50000 h	2550 lm	35 W	190 °	No
SubstiTUBE T5 HF HE35 18 W/4000 K 1463 mm	G5	18 W	105…150 V	50000 h	2800 lm	35 W	190 °	No
SubstiTUBE T5 HF HE35 18 W/6500 K 1463 mm	G5	18 W	105…150 V	50000 h	2800 lm	35 W	190 °	No
SubstiTUBE T5 HF HO49 26 W/3000 K 1463 mm	G5	26 W	80…110 V	50000 h	3600 lm	49 W	190 °	No
SubstiTUBE T5 HF HO54 26 W/3000 K 1163 mm	G5	26 W	40…70 V	50000 h	3600 lm	54 W	190 °	No
SubstiTUBE T5 HF HO49 26 W/4000 K 1463 mm	G5	26 W	80…110 V	50000 h	4000 lm	49 W	190 °	No
SubstiTUBE T5 HF HO54 26 W/4000 K 1163 mm	G5	26 W	40…70 V	50000 h	4000 lm	54 W	190 °	No
SubstiTUBE T5 HF HO49 26 W/6500 K 1463 mm	G5	26 W	80…110 V	50000 h	4000 lm	49 W	190 °	No
SubstiTUBE T5 HF HO54 26 W/6500 K 1163 mm	G5	26 W	40…70 V	50000 h	4000 lm	54 W	190 °	No
SubstiTUBE T5 HF HO80 37 W/3000 K 1463 mm	G5	37 W	60…90 V	50000 h	5050 lm	80 W	190 °	No
SubstiTUBE T5 HF HO80 37 W/4000 K 1463 mm	G5	37 W	60…90 V	50000 h	5600 lm	80 W	190 °	No
SubstiTUBE T5 HF HO80 37 W/6500 K 1463 mm	G5	37 W	60…90 V	50000 h	5600 lm	80 W	190 °	No

SubstiTUBE T5 HF HE35 18 W/4000 K 1463 mm

Product benefits

No bending thanks to glass technology
Quick, simple and safe replacement without rewiring
High luminous flux for sophisticated lighting tasks
Also suitable for operation at low temperatures

View all details

Product data sheet

Go to LEDVANCE successor product

PRODUCT DETAILS

Technical data

Electrical data

Nominal wattage	18 W
Construction wattage	18.00 W
Nominal voltage	105…150 V
Operating mode	ECG
Nominal current	177 mA
Type of current	AC
Inrush current	15 A
Operating frequency	20…75 kHz
Mains frequency	20…75 kHz
Total harmonic distortion	< 20 %
Power factor λ	> 0.90

Photometrical data

Luminous flux	2800 lm
Nominal useful luminous flux 90°	1521 lm
Luminous efficacy	155 lm/W
Lumen main.fact.at end of nom.life time	0.70
Light color (designation)	Cool White
Color temperature	4000 K
Color rendering index Ra	83
Light color	840
Standard deviation of color matching	≤5 sdcm
Flickering metric (Pst LM)	1
Stroboscope effect metric (SVM)	0,4

Light technical data

Beam angle	190 °
Warm-up time (60 %)	‹ 2.00 s
Starting time	< 0.5 s

Dimensions & Weight

Overall length	1463.00 mm
Length with base excl. base pins/connection	1449.00 mm
Diameter	17.00 mm
Tube diameter	16 mm
Maximum diameter	17 mm
Product weight	192.00 g

Temperatures & operating conditions

Ambient temperature range	-20…+45 °C
Maximum temperature at tc test point	62 °C

Lifespan

Lifespan L70/B50 at 25 °C	50000 h
Number of switching cycles	200000
Lumen maintenance at end of service lifetime	0.70
Rated lamp survival factor at 6,000 h	≥ 0.90

Additional product data

Base (standard designation)	G5
Mercury content	0.0 mg
Mercury-free	Yes
Design / version	Frosted

Capabilities

Dimmable

Certificates & Standards

Energy efficiency class	D ¹⁾
Energy consumption	20.00 kWh/1000h
Type of protection	IP20
Standards	CE
Photobiological safety group acc. to EN62778	RG0

¹⁾ Energy efficiency class (EEC) on a scale of A (highest efficiency) to G (lowest efficiency)

Country-specific categorizations

Order reference

LEDTUBE T5 HF H

LOGISTICAL DATA

Temperature range at storage

-20…+80 °C

Energy labelling regulation data acc EU 2019/2015

Lighting technology used	LED
Non-directional or directional	NDLS
Mains or non-mains	NMLS
Light source cap-type (or other electric interface)	G5
Connected light source (CLS)	No
Color-tuneable light source	No
Envelope	No
High luminance light source	No
Anti-glare shield	No
Correlated colour temperature type	SINGLE_VALUE
Standby power	0 W
Networked standby power for CLS	0 W
Claim of equivalent power	No
Length	1463.00 mm
Height	17.00 mm
Width	17.00 mm
Chromaticity coordinate x	0.381
Chromaticity coordinate y	0.379
R9 Colour rendering index	0.00
Beam angle correspondence	SPHERE_360
Survival factor	0.90
Displacement factor	0.90
LED light source replaces a fluorescent light source	No
EPREL ID	642867
Model number	AC35152

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals	Contains at least 10 mg
Quantity of rare earths	Contains at least 1 mg
Minimum rate of recycled material in packaging	80 % ¹⁾
Minimum percentage of recycled content in the product	0 % ¹⁾
Product recyclability	Mostly recyclable product ¹⁾
Packaging recyclability	Mostly recyclable packaging ¹⁾
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage	No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage	Additional info can be provided per individual request
List of substances of very high concern in concentrations greater than 0.1% in mass percentage

¹⁾ According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product description

Product benefits

No bending thanks to glass technology
Quick, simple and safe replacement without rewiring
High luminous flux for sophisticated lighting tasks
Also suitable for operation at low temperatures

Areas of application

General illumination within ambient temperatures from -20…+45 °C
Offices, public buildings
Supermarkets and department stores
Industry

Product features

Retrofit replacement of existing T5 lamps on HF ballast installations
Lamp tube made of glass with splinter protection e.g. for food industry applications
High color consistency: ≤ 5 sdcm
Lifetime up to 50,000 h
Low flicker according to EU 2019-2020 (SVM ≤ 0.4 / PstLM ≤ 1)
Type of protection: IP20
Compatible with many common electronic control gears (see also compatibility list)

Legal advice

When used to replace a T5 fluorescent lamp the total energy efficiency and light distribution depends on the design of the lighting system.

Safety advice

Operation in outdoor applications in suitable damp-proof luminaires possible according to data sheet and installation instruction.
The operating temperature range of LED tube is restricted. In case of doubt regarding suitability of the application please measure Tc temperature on the product prior to installation.
All electrical connections must be made by a qualified person.
Not suitable for emergency lighting.

References / Links

For current information see www.ledvance.com/osram-substitube

GTIN and Packaging information

Product code	Packaging unit (Pieces/Unit)	Dimensions (length x width x height)	Gross weight	Volume
4058075543140	Sleeve 1	1,465 mm x 20 mm x 24 mm	218.00 g	0.70 dm³
4058075543157	Shipping box 10	1,518 mm x 153 mm x 80 mm	2702.00 g	18.58 dm³

Country-specific information

EAN	SEG number	STK number	EFO number	ELDAS number
4058075543140	8296208	4930416	3766287	941807560
