Choose your product version
| Product description | Base (standard designation) | Nominal wattage | Nominal voltage | Nominal lamp life time | Nominal luminous flux |
|---|---|---|---|---|---|
| SIG 1210 | BA20d | 10/10 W | 12 V | 600 h | 137 lm |
| SIG 3015 LL | BA20d | 15/15 W | 30 V | 8800 h | 160 lm |
| SIG 3015 | BA20d | 15/15 W | 30 V | 600 h | 213 lm |
| SIG 1820 LL | BA20d | 20 W | 12 V | 8800 h | |
| SIG 1820 | BA20d | 20/20 W | 12 V | 600 h | 350 lm |
| SIG 1230 | BA20d | 30/30 W | 12 V | 600 h | 520 lm |
| Nominal wattage | 10/10 W |
| Construction wattage | 10.00 W |
| Nominal voltage | 12 V |
| Luminous flux | 137 lm |
| Luminous efficacy | 13 lm/W |
| Color rendering index Ra | 100 |
| Light color | 10 |
| Starting time | 0 s |
| Overall length | 67.00 mm |
| Light center length (LCL) | 29,6 mm 1) |
| Diameter | 36,0 mm |
| Product weight | 18.37 g |
1) Distance from the coil to the lug of base
| Lifespan L70/B50 at 25 °C | 600 h |
| Base (standard designation) | BA20d |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Design / version | Bulb |
| Burning position | hs30 |
| Order reference | 1210 |
| Light source cap-type (or other electric interface) | BA20d |
| Length | 67.00 mm |
| Height | 36,0 mm |
| Width | 36,0 mm |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4050300832173 | Unpacked 1 |
18.40 g | ||
| 4050300218175 | Folding box 10 |
|||
| 4099854217647 | Shipping box 200 |
410 mm x 400 mm x 179 mm | 4673.00 g | 29.36 dm³ |
