Choose your product version
| Product description |
|---|
| FLEX CONTROL UNIT IOT DALI-2 HCL TW |
| Nominal wattage | 20.00 W |
| Nominal voltage | 220…240 V |
| Type of current | DC |
| Input current | 120 mA |
| Mains frequency | 50…60 Hz |
| Operating frequency | 50/60 Hz |
| Length | 91.00 mm |
| Width | 106.00 mm |
| Height | 62.00 mm |
| Cable cross-section, input side | 0.5…2.5 mm² |
| Wire preparation length, input side | 10…12 mm |
| Product weight | 247.00 g |
| Product color | Light grey |
| Ambient temperature range | -20…+50 °C |
| Maximum temperature at tc test point | 70 °C |
| Temperature range in operation | -20…+50 °C |
| Number of switching cycles | 30000 |
| Number of control outputs | 2 |
| Max. connectable push button couplers / sensors | 126 |
| Max. number of connected drivers | 128 |
| Commissioning App | Software |
| Light control tool App | App (Android/ iOS) |
| Groups | 32 |
| Dimmable | No |
| Dimming interface | DALI-2 |
| Number of control outputs | 2 |
| Type of installation | Integrated in flush device box |
| Approval marks – approval | CE |
| Protection class | II |
| Type of protection | IP20 |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075841888 | Folding box 1 |
112 mm x 94 mm x 72 mm | 284.00 g | 0.76 dm³ |
| 4058075841895 | Shipping box 20 |
235 mm x 199 mm x 372 mm | 5905.00 g | 17.40 dm³ |
| EAN | SEG number | EFO number |
|---|---|---|
| 4058075841888 | 1361152 | 4545455 |
