Choose your product version
| Product description | Dimmable |
|---|---|
| DP HOUSING DALI 1200 P 1XLAMP IP65 | Yes |
| DP HOUSING DALI 1200 P 2XLAMP IP65 | Yes |
| DP HOUSING DALI 1500 P 1XLAMP IP65 | Yes |
| DP HOUSING DALI 1500 P 2XLAMP IP65 | Yes |
| Nominal voltage | 220…240 V |
| Mains frequency | 0/50/60 Hz |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Flickering metric (Pst LM) | < 1 |
| Stroboscope effect metric (SVM) | < 0.4 |
| Length | 1585.00 mm |
| Height | 70.00 mm |
| Width | 65.00 mm |
| Product weight | 1110.00 g |
| Product color | Gray |
| Housing color | Gray |
| Body material | Polycarbonate (PC) |
| Cover material | Polycarbonate (PC) |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 850 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+80 °C |
| Type of connection | Screwless terminal, 5-Pole (L, N, PE, DA+, DA-) |
| Type of protection | IP65 |
| Protection class IK (shock resistance) | IK08 |
| Dimmable | Yes |
| Type of dimming | DALI2 |
| Mounting type | Surface |
| Mounting location | Ceiling |
| Application environment | Indoor |
| With light source | No |
| Holder designation | G13 |
| ECG - Output ripple current | ≤ 5 % |
| Standards | CE, TÜV Rheinland, EAC, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Product remark | When used in very cold applications as in cold storage, a special membrane might be required to ensure lifetime |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854146480 | Folding box 1 |
68 mm x 1,577 mm x 75 mm | 1280.00 g | 8.04 dm³ |
| 4099854146497 | Shipping box 6 |
1,592 mm x 216 mm x 162 mm | 8330.00 g | 55.71 dm³ |
| 4099854246050 | Shipping box 9 |
1,592 mm x 216 mm x 237 mm | 12170.00 g | 81.50 dm³ |
| EAN | STK number | ELDAS number |
|---|---|---|
| 4099854146480 | 4324872 | 941005430 |
