SURFACE CIRCULAR FRAME

Choose your product version

OVERVIEW

Product description Beam angle
SF CIRCULAR 500 FRAME WT 120 °
SF CIRCULAR 500 FRAME BK 120 °


SF CIRCULAR 500 FRAME WT

Product benefits
  • Design extension for a more decorative appearance
  • Allows direct light as well as accentuated light to the ceiling
  • Easy and quick installation

PRODUCT DETAILS

Photometrical data

Beam angle 120 °

Dimensions & Weight

Diameter 560 mm
Height 105.00 mm
Product weight 2400.00 g

Materials & Colors

Product color White
Body material Steel

Application & Mounting

Mounting type Surface
Mounting location Ceiling

Certificates & Standards

Ball shot safe No

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals 0 mg
Quantity of rare earths 0 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage Additional info can be provided per individual request
List of substances of very high concern in concentrations greater than 0.1% in mass percentage

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Design extension for a more decorative appearance
  • Allows direct light as well as accentuated light to the ceiling
  • Easy and quick installation
Areas of application
  • Extension for SURFACE CIRCULAR 500
Product features
  • Available in black / gold (like RAL790-5 / RAL260-M) and white (like RAL110-1) color
  • Metal sheet frame
Equipment / Accessories
  • Replacement cover optionally available
References / Links
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4058075834187 Folding box
1
112 mm x 567 mm x 560 mm 2125.00 g 35.56 dm³
4058075834194 Shipping box
5
585 mm x 585 mm x 605 mm 12515.00 g 207.05 dm³
EAN SEG number STK number EFO number
4058075834187 7510806 4152027 3361427
