Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| Ceiling Essential 250mm 13W 3000K | 13.00 W | 50000 | 120 ° | 920 lm | No |
| Ceiling Essential 250mm 13W 4000K | 13.00 W | 50000 | 120 ° | 960 lm | No |
| Ceiling Essential 250mm 13W 6500K | 13.00 W | 50000 | 120 ° | 960 lm | No |
| Ceiling Essential 400mm 24W 3000K | 24.00 W | 50000 | 120 ° | 1920 lm | No |
| Ceiling Essential 400mm 24W 4000K | 24.00 W | 50000 | 120 ° | 1920 lm | No |
| Ceiling Essential 400mm 24W 6500K | 24.00 W | 50000 | 120 ° | 1920 lm | No |
| Nominal wattage | 13.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 65.000 mA |
| Inrush current time Th50 | 6.6 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 98 |
| Max. number of luminaires per miniature circuit breaker C16 | 123 |
| Power factor λ | > 0.70 |
| Total harmonic distortion | < 70 % |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Luminous flux | 920 lm |
| Total luminous flux of contained light sources | 1300 lm |
| Luminous efficacy | 70 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 6 sdcm |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Photobiological safety group acc. to EN62778 | RG0 |
| Photobiological safety group acc. to EN62471 | RG0 |
| Beam angle | 120 ° |
| Diameter | 250.00 mm |
| Height | 91.00 mm |
| Product weight | 330.00 g |
| Product color | White |
| Housing color | White |
| Body material | Plastic |
| Cover material | Polymethylmethacrylate (PMMA) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Type of connection | Cable, 3-pole |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | No |
| Mounting type | Surface |
| Application environment | Indoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 20000 h 1) |
| Number of switching cycles | 50000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Number of illuminants | empty |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075762473 | Folding box 1 |
280 mm x 98 mm x 282 mm | 470.00 g | 7.74 dm³ |
| 4058075762480 | Shipping box 10 |
575 mm x 510 mm x 305 mm | 5222.00 g | 89.44 dm³ |
