Essentials Ceiling

Choose your product version

OVERVIEW

Product description Nominal wattage Number of switching cycles Beam angle Luminous flux Dimmable
Ceiling Essential 250mm 13W 3000K 13.00 W 50000 120 ° 920 lm No
Ceiling Essential 250mm 13W 4000K 13.00 W 50000 120 ° 960 lm No
Ceiling Essential 250mm 13W 6500K 13.00 W 50000 120 ° 960 lm No
Ceiling Essential 400mm 24W 3000K 24.00 W 50000 120 ° 1920 lm No
Ceiling Essential 400mm 24W 4000K 24.00 W 50000 120 ° 1920 lm No
Ceiling Essential 400mm 24W 6500K 24.00 W 50000 120 ° 1920 lm No


Ceiling Essential 400mm 24W 4000K

Product benefits
  • Simple installation thanks to light-weight design
  • Decorative wall light

PRODUCT DETAILS

Electrical data

Nominal wattage 24.00 W
Nominal voltage 220…240 V
Mains frequency 50…60 Hz
Nominal current 115.000 mA
Inrush current time Th50 8.6 µs
Max. number of luminaires per miniature circuit breaker B16 69
Max. number of luminaires per miniature circuit breaker C16 83
Power factor λ > 0.70
Total harmonic distortion 70 %
Protection class I
Operating mode Integrated LED driver

Photometrical data

Luminous flux 1920 lm
Total luminous flux of contained light sources 3100 lm
Luminous efficacy 80 lm/W
Color temperature 4000 K
Light color (designation) Cool White
Color rendering index Ra > 80
Standard deviation of color matching < 6 sdcm
Flickering metric (Pst LM) -
Stroboscope effect metric (SVM) -
Photobiological safety group acc. to EN62778 RG0
Photobiological safety group acc. to EN62471 RG0
Beam angle 120 °

Dimensions & Weight

Diameter 400.00 mm
Height 120.00 mm
Product weight 660.00 g

Materials & Colors

Product color White
Housing color White
Body material Plastic
Cover material Polymethylmethacrylate (PMMA)
Glow Wire Test according to IEC 60695-2-12 650 °C

Application & Mounting

Ambient temperature range -20…+40 °C
Type of connection Cable, 3-pole
Type of protection IP20
Protection class IK (shock resistance) IK03
Dimmable No
Mounting type Surface
Application environment Indoor
With light source Yes

Lifespan

Lifespan L70/B50 at 25 °C 20000 h 1)
Number of switching cycles 50000

1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Certificates & Standards

Standards CE, UKCA
Luminaire with limited surface temperature, "D sign" No
Ball shot safe No
Replaceable light source (EPREL) Not replaceable

Additional product data

Number of illuminants empty

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals Contains at least 10 mg
Quantity of rare earths Contains at least 1 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage Yes
List of substances of very high concern in concentrations greater than 0.1% in mass percentage Lead (7439-92-1)

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Simple installation thanks to light-weight design
  • Decorative wall light
Areas of application
  • Living areas
Product features
  • Wall and ceiling luminaire
Equipment / Accessories
  • Mounting screws and dowels included
Safety advice
  • All electrical connections must be made by a qualified person.
  • Caution, risk of electric shock.
  • Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
  • Check wall-ceiling for suitability. If uncertain, seek professional advice.
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4099854003134 Folding box
1
130 mm x 440 mm x 440 mm 1042.00 g 25.17 dm³
4099854003141 Shipping box
5
665 mm x 455 mm x 460 mm 6516.00 g 139.18 dm³
