Choose your product version
| Product description | Beam angle | Dimmable |
|---|---|---|
| DP HOUSING 1200 2x Lamp IP65 | 105 ° | No |
| DP HOUSING 1500 1x Lamp IP65 | 105 ° | No |
| DP HOUSING 1500 2x Lamp IP65 | 105 ° | No |
| DP HOUSING 1200 1x Lamp IP65 | 105 ° | No |
| DP HOUSING 600 1x Lamp IP65 | 105 ° | No |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Protection class | I |
| Luminous intensity | - |
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
| Beam angle | 105 ° |
| Length | 1261.00 mm |
| Height | 75.00 mm |
| Width | 103.00 mm |
| Product weight | 1300.00 g |
| Product color | Grey |
| Housing color | Gray |
| Body material | Polycarbonate (PC) |
| Cover material | Polycarbonate (PC) |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+45 °C |
| Temperature range at storage | -20…80 °C |
| Type of connection | Screw terminal |
| Type of protection | IP65 |
| Protection class IK (shock resistance) | IK08 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling |
| Application environment | Indoor |
| With light source | No |
| Standards | CE, TÜV Rheinland, EAC, ROHS, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Number of illuminants | - |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075312456 | Folding box 1 |
110 mm x 79 mm x 1,265 mm | 1363.00 g | 10.99 dm³ |
| 4058075312463 | Shipping box 6 |
1,280 mm x 231 mm x 245 mm | 10141.00 g | 72.44 dm³ |
| Product image | Product name | EAN |
|---|---|---|
|
DP HOUSING 1200 2xLAMP TH-KIT 5x2.5 | 4058075695115 |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4058075312456 | 7215004 | 4315568 | 3304024 | 941000750 |
