Choose your product version
| Product description | Dimmable |
|---|---|
| LN MAG BATTEN T5 568 | No |
| LN MAG BATTEN T5 868 | No |
| LN MAG BATTEN T5 1168 | No |
| LN MAG BATTEN T5 1468 | No |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Protection class | I |
| Operating mode | Mains voltage |
| Length | 568.00 mm |
| Height | 45.00 mm |
| Width | 25.00 mm |
| Product weight | 380.00 g |
| Cable length | 400 mm |
| Product color | White |
| Housing color | White |
| Body material | Steel |
| Glow Wire Test according to IEC 60695-2-12 | 850 °C |
| Ambient temperature range | -20…+45 °C |
| Temperature range at storage | -20…80 °C |
| Type of connection | Screwless terminal, 3-Pole |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK02 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling |
| Application environment | Indoor |
| With light source | No |
| Holder designation | G5 |
| Standards | CE, ENEC, TÜV Rheinland, UKCA, EAC |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Number of illuminants | 1 |
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854009723 | Folding box 1 |
70 mm x 582 mm x 37 mm | 438.00 g | 1.51 dm³ |
| 4099854009730 | Shipping box 10 |
604 mm x 372 mm x 90 mm | 4756.00 g | 20.22 dm³ |
| EAN | SEG number | STK number | EFO number |
|---|---|---|---|
| 4099854009723 | 7218158 | 4136168 | 3310288 |
