Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| LB FLEX 1200 P 42W 840 N | 42 W | 50000 | 60 ° | 6510 lm | No |
| LB FLEX 1200 P 42W 840 W | 42 W | 50000 | 90 ° | 6510 lm | No |
| LB FLEX 1200 P 42W 840 VW | 42 W | 50000 | 120 ° | 6510 lm | No |
| LB FLEX 1200 P 42W 840 OV | 42 W | 50000 | 40 ° x 90 ° | 6510 lm | No |
| LB FLEX 1200 P 73W 840 N | 73 W | 50000 | 60 ° | 11315 lm | No |
| LB FLEX 1200 P 73W 840 W | 73 W | 50000 | 90 ° | 11315 lm | No |
| LB FLEX 1200 P 73W 840 VW | 73 W | 50000 | 120 ° | 11315 lm | No |
| LB FLEX 1200 P 73W 840 OV | 73 W | 50000 | 40 ° x 90 ° | 11315 lm | No |
| Nominal wattage | 73 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 320 mA |
| Inrush current | 25.24 A |
| Inrush current time Th50 | 436 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 13 |
| Max. number of luminaires per miniature circuit breaker C10 | 13 |
| Max. number of luminaires per miniature circuit breaker C16 | 22 |
| Power factor λ | ≥0.90 |
| Total harmonic distortion | ≤ 20 % |
| Protection class | I |
| Operating mode | Electronic control gear (ECG) |
| Luminous flux | 11315 lm |
| Luminous efficacy | 155 lm/W |
| Color temperature | 4000 K |
| Light color (designation) | Cool White |
| Color rendering index Ra | ≥80 |
| Standard deviation of color matching | < 3 sdcm |
| Low flicker | Yes |
| Photobiological safety group acc. to EN62778 | RG1 |
| Photobiological safety group acc. to EN62471 | RG1 |
| Beam angle | 90 ° |
| Length | 1236 mm |
| Height | 65.00 mm |
| Width | 115.00 mm |
| Product weight | 3400.00 g |
| Product color | White |
| Housing color | White |
| Body material | Steel |
| Cover material | Polycarbonate (PC) |
| Light emitting surface material | Polycarbonate (PC) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -25…+50 °C |
| Temperature range at storage | -20…+80 °C |
| Type of connection | Screwless terminal |
| Type of protection | IP23 |
| Protection class IK (shock resistance) | IK08 |
| Dimmable | No |
| Mounting type | Surface/Suspended |
| Mounting location | Ceiling |
| Application environment | Indoor |
| Adjustable | No |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 100000 h 1) |
| Lifespan L80/B10 at 25 °C | 100000 h 1) |
| Lifespan L90/B10 at 25 °C | 83000 h |
| Number of switching cycles | 50000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Output current | 310 mA |
| ECG - Output ripple current | < 10 % |
| Standards | CE, CB, ENEC, TÜV SÜD, EAC, UKCA, EPD |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| EPD | LEDV-00020-V01.01-EN |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Additional info can be provided per individual request |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4058075676107 | Folding box 1 |
106 mm x 1,282 mm x 154 mm | 4255.00 g | 20.93 dm³ |
| 4058075676114 | Shipping box 3 |
1,312 mm x 488 mm x 143 mm | 13901.00 g | 91.56 dm³ |
| Product image | Product name | EAN |
|---|---|---|
|
LB FLEX SUSPENSION KIT | 4058075693722 |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4058075676107 | 7216970 | 4324739 | 3311406 | 941309830 |
