Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| SF SQUARE 330 SEN V 24W 830 IP44 | 24.00 W | 100000 | 120 ° | 2000 lm | No |
| SF SQUARE 330 SEN V 24W 840 IP44 | 24.00 W | 100000 | 120 ° | 2000 lm | No |
| Nominal wattage | 24.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 115.000 mA |
| Inrush current | 7,2 A |
| Inrush current time Th50 | 5.9 µs |
| Max. number of luminaires per miniature circuit breaker B16 | 104 |
| Max. number of luminaires per miniature circuit breaker C10 | 66 |
| Max. number of luminaires per miniature circuit breaker C16 | 106 |
| Power factor λ | > 0.70 |
| Total harmonic distortion | < 60 % |
| Protection class | I |
| Operating mode | Integrated LED driver |
| Luminous flux | 2000 lm |
| Luminous efficacy | 83 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | < 6 sdcm |
| Low flicker | Yes |
| Flickering metric (Pst LM) | < 1 |
| Stroboscope effect metric (SVM) | < 0.4 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Beam angle | 120 ° |
| Length | 330.00 mm |
| Height | 75.00 mm |
| Width | 330.00 mm |
| Product weight | 690.00 g |
| Product color | White |
| Housing color | White |
| Body material | Steel |
| Cover material | Polymethylmethacrylate (PMMA) |
| Light emitting surface material | PMMA |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+80 °C |
| Type of connection | Terminal, 3-pin |
| Type of protection | IP44 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Ceiling, Wall |
| Application environment | Indoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 35000 h 1) |
| Lifespan L80/B10 at 25 °C | 33000 h 1) |
| Lifespan L90/B10 at 25 °C | 15000 h |
| Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Output current | 300 mA |
| ECG - Output ripple current | < 5 % |
| Type of sensor | Motion, Light |
| Sensor technology | Microwave |
| Sensor detection angle | 120 ° |
| Sensor controlled switching time | 5 s…30 min |
| Detection range of motion sensor | 4…7 m |
| Detection threshold of daylight sensor | 2…50 lx |
| Sensor IK rating | IK03 |
| Standards | CE, CB, TÜV, UKCA, EAC |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
| Replaceable light source (EPREL) | Not replaceable |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | Yes |
| List of substances of very high concern in concentrations greater than 0.1% in mass percentage | Lead (7439-92-1) |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854041990 | Folding box 1 |
87 mm x 367 mm x 369 mm | 951.00 g | 11.78 dm³ |
| 4099854042003 | Shipping box 5 |
457 mm x 387 mm x 404 mm | 5946.00 g | 71.45 dm³ |
| EAN | SEG number | STK number | EFO number | ELDAS number |
|---|---|---|---|---|
| 4099854041990 | 7510653 | 4136272 | 3310301 | 941005320 |
