Choose your product version
| Product description | Nominal wattage | Number of switching cycles | Beam angle | Luminous flux | Dimmable |
|---|---|---|---|---|---|
| Orbis Slim Moia 280mm 20W White | 20.00 W | 25000 | 120 ° | 1500 lm | No |
| Orbis Slim Moia 280mm 20W Black | 20.00 W | 25000 | 120 ° | 1500 lm | No |
| Orbis Slim Moia 480mm 36W White | 36.00 W | 25000 | 120 ° | 2700 lm | No |
| Orbis Slim Moia 480mm 36W Black | 36.00 W | 25000 | 120 ° | 2700 lm | No |
| Orbis Slim Moia 380mm 24W 830 WT | 24.00 W | 25000 | 120 ° | 1800 lm | No |
| Orbis Slim Moia 380mm 24W 830 BK | 24.00 W | 25000 | 120 ° | 1800 lm | No |
| Nominal wattage | 36.00 W |
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Nominal current | 160.000 mA |
| Inrush current | 3 A |
| Inrush current time Th50 | 100 µs |
| Power factor λ | > 0.90 |
| Total harmonic distortion | < 70 % |
| Protection class | I |
| Operating mode | Mains voltage |
| Luminous flux | 2700 lm |
| Total luminous flux of contained light sources | 4500 lm |
| Luminous efficacy | 75 lm/W |
| Color temperature | 3000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | > 80 |
| Standard deviation of color matching | 6 sdcm |
| Flickering metric (Pst LM) | <1 |
| Stroboscope effect metric (SVM) | <0.4 |
| Photobiological safety group acc. to EN62778 | RG0 |
| Photobiological safety group acc. to EN62471 | RG0 |
| Beam angle | 120 ° |
| Diameter | 480.00 mm |
| Height | 50.00 mm |
| Product weight | 1970.00 g |
| Product color | Black |
| Housing color | Black |
| Body material | Steel |
| Cover material | Polymethylmethacrylate (PMMA) |
| Glow Wire Test according to IEC 60695-2-12 | 650 °C |
| Mercury content | 0.0 mg |
| Ambient temperature range | -20…+40 °C |
| Temperature range at storage | -20…+60 °C |
| Type of connection | Terminal, 3-Pole (L, N, PE) |
| Type of protection | IP20 |
| Protection class IK (shock resistance) | IK03 |
| Dimmable | No |
| Mounting type | Surface |
| Application environment | Indoor |
| With light source | Yes |
| Lifespan L70/B50 at 25 °C | 50000 h 1) |
| Number of switching cycles | 25000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
| Standards | CE, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Replaceable light source (EPREL) | Not replaceable |
| Number of illuminants | empty |
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
| Minimum rate of recycled material in packaging | 80 % 1) |
| Minimum percentage of recycled content in the product | 0 % 1) |
| Product recyclability | Mostly recyclable product 1) |
| Packaging recyclability | Mostly recyclable packaging 1) |
| List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage | No |
| Contains substances of very high concern in concentrations greater than 0.1% by mass percentage | No |
1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)
| Product code | Packaging unit (Pieces/Unit) | Dimensions (length x width x height) | Gross weight | Volume |
|---|---|---|---|---|
| 4099854092480 | Folding box 1 |
58 mm x 490 mm x 490 mm | 2275.00 g | 13.93 dm³ |
| 4099854092497 | Shipping box 4 |
510 mm x 255 mm x 520 mm | 10054.00 g | 67.63 dm³ |
