OSRAM DULUX D

Choose your product version

Phase out

10 W/827

Phase out

13 W/865

Phase out

13 W/827

Phase out

13 W/830

Phase out

13 W/840

Phase out

18 W/865

Phase out

18 W/827

Phase out

18 W/830

Phase out

18 W/840

Phase out

26 W/865

Phase out

26 W/827

Phase out

26 W/830

Phase out

26 W/840

OVERVIEW

Product description Base (standard designation) Nominal wattage Nominal voltage Nominal lamp life time Nominal luminous flux Dimmable
DULUX D 10 W/827 G24d-1 10 W 64 V 10000 h 600 lm No
DULUX D 13 W/865 G24d-1 13 W 91 V 10000 h 825 lm No
DULUX D 13 W/827 G24d-1 13 W 91 V 10000 h 870 lm No
DULUX D 13 W/830 G24d-1 13 W 91 V 10000 h 870 lm No
DULUX D 13 W/840 G24d-1 13 W 91 V 10000 h 870 lm No
DULUX D 18 W/865 G24d-2 18 W 100 V 10000 h 1100 lm No
DULUX D 18 W/827 G24d-2 18 W 100 V 10000 h 1200 lm No
DULUX D 18 W/830 G24d-2 18 W 100 V 10000 h 1200 lm No
DULUX D 18 W/840 G24d-2 18 W 100 V 10000 h 1200 lm No
DULUX D 26 W/865 G24d-3 26 W 105 V 10000 h 1600 lm No
DULUX D 26 W/827 G24d-3 26 W 105 V 10000 h 1750 lm No
DULUX D 26 W/830 G24d-3 26 W 105 V 10000 h 1750 lm No
DULUX D 26 W/840 G24d-3 26 W 105 V 10000 h 1750 lm No
Phase out


DULUX D 13 W/830

Product benefits
  • Improved maintenance
View all details
Product data sheet

PRODUCT DETAILS

Electrical data

Nominal wattage 13 W
Construction wattage 13.90 W
Nominal voltage 91 V
Nominal current 0.18 A

Photometrical data

Luminous flux 870 lm
Luminous efficacy 63 lm/W
Light color (designation) LUMILUX Warm White
Color temperature 3000 K
Color rendering index Ra ≥80
Light color 830
Rated LLMF at 2,000 h 0.85
Rated LLMF at 4,000 h 0.78
Rated LLMF at 6,000 h 0.76
Rated LLMF at 8,000 h 0.75

Dimensions & Weight

Overall length 138.00 mm
Length with base excl. base pins/connection 115,00 mm
Diameter 12.00 mm
Tube diameter 12 mm
Product weight 37.5 g

Temperatures & operating conditions

Ambient temperature range -5…+40 °C

Lifespan

Service life 6500 h
Rated lamp survival factor at 2,000 h 0.99
Rated lamp survival factor at 4,000 h 0.99
Rated lamp survival factor at 6,000 h 0.95
Rated lamp survival factor at 8,000 h 0.81
Lifespan B50 10000 h

Additional product data

Base (standard designation) G24d-1
Mercury content 1.6 mg

Capabilities

Dimmable No

Certificates & Standards

Energy efficiency class G
Energy consumption 14.00 kWh/1000h

Country-specific categorizations

ILCOS FSQ-13/830-I-G24d-1
Order reference DULUX D 13W/830

Energy labelling regulation data acc EU 2019/2015

Lighting technology used CFLNI
Non-directional or directional NDLS
Mains or non-mains NMLS
Light source cap-type (or other electric interface) G24d-1
Connected light source (CLS) No
Color-tuneable light source No
Envelope No
High luminance light source No
Anti-glare shield No
Correlated colour temperature type SINGLE_VALUE
Claim of equivalent power No
Length 138.00 mm
Height 12.00 mm
Width 12.00 mm
Chromaticity coordinate x 0,440
Chromaticity coordinate y 0,403
Beam angle correspondence SPHERE_360
EPREL ID 546428
Model number AC34203

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals 0 mg
Quantity of rare earths 0 mg
Minimum rate of recycled material in packaging 80 % 1)
Minimum percentage of recycled content in the product 0 % 1)
Product recyclability Mostly recyclable product 1)
Packaging recyclability Mostly recyclable packaging 1)
List of dangerous substances contained in the product in concentrations greater than 0.1% in mass percentage No
Contains substances of very high concern in concentrations greater than 0.1% by mass percentage Additional info can be provided per individual request
List of substances of very high concern in concentrations greater than 0.1% in mass percentage

1) According to AGEC Decree 2022-748 (French Anti-Waste-Legislation for a Circular Economy)

Product benefits
  • Improved maintenance
Areas of application
  • Offices, public buildings
  • Shops
  • Supermarkets and department stores
  • Hotels, restaurants
  • Industry
Product features
  • Good color rendering index
  • Short and compact pin-base lamp with double-turn tubes
  • Single-ended two-pin plug-in G24d base
Equipment / Accessories
  • Suitable for operation on conventional control gear
Safety advice
Product code Packaging unit (Pieces/Unit) Dimensions (length x width x height) Gross weight Volume
4050300025698 Folding box
1		 35 mm x 35 mm x 145 mm 52.00 g 0.18 dm³
4050300257969 Shipping box
10		 187 mm x 81 mm x 163 mm 566.50 g 2.47 dm³
Declarations of conformity
EC Declaration of Conf ormity - 2021 9C1-4077 878-EN-00 - DULUX D PDF (43.21 KB)
Certificates
EAC RU C-DE.HA46.B.011 31_21 21.05.2021-20.05 .2026 Expert Certifica tion - CFLpin PDF (1.18 MB)
Certificates
EAC N RU D-DE.MU62.B.0 0933_20 06.03.2020-05. 03.2025 Prommash Test - CFLpin PDF (1.12 MB)
Product image: white background, diagonal
323942_DULUX D TIF (1.83 MB)
Product image: white background, upright
327054_DULUX D TIF (14.8 MB)
Product line drawing with letters
319452_DULUX D, D/E, D /E XT FOR ECG SVG (11.84 KB)
Product line drawing with numbers
325717_DULUX D, D/E, D /E XT FOR ECG SVG (19.69 KB)
Product line drawing with numbers
552_DULUX D SVG (5.83 KB)
Product line drawing, front, no dimensions
39467_DULUX D, D/E, D/ E XT FOR ECG SVG (7.88 KB)
Product line drawing, front, no dimensions
33628_OSRAM DULUX D SVG (4.7 KB)
Product line drawing, front, no dimensions
325431_DULUX D ES SVG (7.88 KB)
Energy label
EL-4050300025698-AC342 03 PDF (21.45 KB)
Logos and pictos
G left SVG (2.41 KB)
Logos and pictos
G left BW SVG (1.07 KB)
Logos and pictos
G right SVG (2.4 KB)
Logos and pictos
G right BW SVG (1.06 KB)
Spectral power distribution
349617_FL_830 PNG (92.09 KB)
EAN SEG number STK number EFO number ELDAS number
4050300025698 8330130 4933875 3820413 946161110
